HONEYWELL CC-PCF901

●制造商:霍尼韦尔

●产品编号:CC- PCF901

●产品类型:控制防火墙模块

●为多个C系列FIM提供高效的FTE电缆分配。

●模块安装在CF9输入/输出终端组件(IOTA)上。

●向机柜内网络节点提供FTE分布。(C300控制器和C系列模切

●电源额定值:0.112A @ 24VDC

●运输重量:2公斤
