FS7-2173-2RP 光电火焰探测器 二级火灾探测响应

☆型号：FS7-2173-2RP 光电火焰探测器 二级火灾探测响应

【产品详情】

FS7 火灾和火焰探测器 霍尼韦尔FS7-2173-2RP 火焰探测器

光电火焰探测器，特别适合半导体行业洁净室火灾防护应用

火焰探测器

采用宽带红外、窄带红外、可见光多光谱光学技术，特别应用于半导体无尘室防护的

Fire Sentry FS7 型火焰探测器。

FS7火焰探测仪对半导体行业的湿式操作台火焰提供智能化两级响应。

一级：警告。第一级响应表示小的火灾事故，热能量仅超过3KW(相当于4英寸直径的聚

丙烯的一团火)，等待一段时间，判断是否可自行熄灭。

二级：报警。如果火不能自行熄灭，并超过工厂设定的13KW(相当于8英寸直径的聚丙烯

的一团火)阈值，探测器启动二级响应。

多光谱 、近红外波段和可见光波段火灾探测器适用于半导体洁净室内的火灾防护应用。

特点与优点

二级火灾探测响应

不受错误报警源影响

可探测烃类和非烃类火灾

规格一览

视野范围：120°（水平和垂直方向）

工作电压：标称 24 V 直流电（18-32 V 直流电） - 稳压

工作温度范围：32° 至 +158°F（0 至 70°C）                                             产品概述

FS7 火灾探测器为半导体湿式工作台火灾提供智能化二级响应：

第 1 级：警示。这是发生小型火灾（产生 3 千瓦的热能，相当于直径为 4 英寸的聚丙烯油池着火时产生的热量）时的第一级响应。第一级响应为火焰自行熄灭提供了一定时间。

第 2 级：报警。如果火焰不能自行熄灭，达到 Factory Mutual 规定的热能阈值（即 13 千瓦，相当于直径为 8 英寸的聚丙烯油池着火时产生的热量），就会激活第 2 级响应。

FS7-2173 与 FS7-130-SX 控制器或控制面板 FSWB 一同使用。控制器和控制面板向探测器供电，监控所有探测器的状态并通过数字式 RS-485 通道与各探测器进行通讯。 FS7-2173 提供标准的 20 英尺电缆连接器。探测器通过自锁接头和 接线盒连接到控制器或控制面板上。这种连接方式快速简便，不会产生接线问题。每个探测器都可在其非易失性存储器中存储多达六组标有时间和日期的 FirePics™（事件前多光谱传感器阵列数据）。控制器和控制面板也可在其非易失性存储器中存储事件历史表，其中包括标有时间和日期的警示、警报和故障历史。可从控制器或控制面板检索 FirePics™ 和事件历史。

FS7-2173-2RP 单元化模型的微处理器（包含数字信号处理算法）可持续监控电路、传感器的内置自检功能，还可验证运行是否正确。带分立继电器输出的 FS7-2173-2RP 可作为独立式探测器运行，亦可与任何经过认可的火灾报警面板连接。该探测器需要外接 24 V 直流电电源，并提供标准的 20 英尺尾缆。可在其非易失性存储器中存储多达六组标有时间和日期的 FirePics™ 和 200 起事件。FirePics™ 和事件历史可使用 FS7 接口套件和基于 Windows 的 PC 软件进行检索。

其他特点和优点：

多光谱数字式电光辐射能红外火灾探测器

二级火灾探测响应

不受错误报警源影响

不受吸入烟雾、气体或化学蒸汽的影响

对电热器和烤炉产生的背景辐射能不敏感

可探测烃类和非烃类火灾

坚固、防漏、热封、耐酸，并且具有注射成型聚丙烯外壳

120° 宽视野范围

可通过 RS-485 接口进行数字通讯

FirePic™；数字式火焰信号标有时间和日期

内置探测器可自动执行自检

单元化模型设计可实现独立运行

☆型号：FS7-2173-2RP 光电火焰探测器 二级火灾探测响应

【英文介绍】

FS7 Fire and Flame detector Honeywell FS7-2303-2RP fire detector

Photoelectric flame detector, especially suitable for clean room fire protection applications in the semiconductor industry

Flame detector

Broadband infrared, narrow band infrared, visible light multi-spectral optical technology, especially used in semiconductor clean room protection

Fire Sentry FS7 flame detector.

The FS7 flame detector provides an intelligent two-stage response to the wet platform flame in the semiconductor industry.

Level 1: Warning. The first level response indicates a small fire incident with a thermal energy of just over 3KW(equivalent to a 4-inch diameter cluster)

A fire of propylene), wait for a period of time to determine whether it can be extinguished by itself.

Level 2: Alarm. If the fire does not extinguish itself, and exceeds the factory set 13KW(equivalent to 8-inch diameter polypropylene)

A fire) threshold, the detector initiates a secondary response.

Multispectral, near-infrared and visible light fire detectors are suitable for fire protection applications in semiconductor clean rooms.

Features and advantages

Level two fire detection response

Immune to false alarm sources

Hydrocarbon and non-hydrocarbon fires can be detected

List of specifications

Field of view: 120° (horizontal and vertical directions)

Operating voltage: Nominal 24 V DC (18-32 V DC) - voltage regulation

Operating temperature range: 32° to +158°F (0 to 70°C) Product Overview

FS7 fire detector provides intelligent secondary response for semiconductor wet bench fires:

Level 1: Warning. This is the first stage response in the event of a small fire (generating 3 kilowatts of thermal energy, equivalent to the heat generated when a 4-inch diameter polypropylene oil pool catches fire). The first response provides a certain amount of time for the flame to self-extinguish.

Level 2: Alarm. If the flame fails to quench on its own and reaches the thermal energy threshold specified by Factory Mutual (i.e., 13 kilowatts, equivalent to the heat generated by a fire in an 8-inch diameter polypropylene oil pool), a stage 2 response is activated.

The FS7-2173 is used with the FS7-130-SX controller or control panel FSWB. The controller and control panel supply power to the detectors, monitor the status of all detectors and communicate with each detector through a digital RS-485 channel. The FS7-2173 offers standard 20-foot cable connectors. The detector is connected to the controller or control panel via a self-locking connector and junction box. This connection method is quick and easy, and does not cause wiring problems. Each detector can store up to six sets of FirePics™ (Pre-event Multispectral Sensor Array data) labeled with time and date in its non-volatile memory. Controllers and control panels may also store event history tables in their non-volatile memory, including warnings, alarms, and failure histories labeled with time and date. FirePics™ and event history can be retrieved from the controller or control panel.

The FS7-2173-2RP unit model of the microprocessor (including digital signal processing algorithms) can continuously monitor the circuit, the built-in self-check function of the sensor, and verify that the operation is correct. The FS7-2303-2RP with discrete relay output can be operated as a standalone detector and can be connected to any approved fire alarm panel. The detector requires an external 24 V DC power supply and is supplied with a standard 20-foot stern cable. Up to six sets of FirePics™ and 200 events labeled with time and date can be stored in its non-volatile memory. FirePics™ and event history can be retrieved using the FS7 interface suite and Windows-based PC software.

Other features and benefits:

Multispectral digital electro-optic radiant energy infrared fire detector

Level two fire detection response

Immune to false alarm sources

Not affected by inhaling fumes, gases or chemical vapors

It is not sensitive to the background radiation energy generated by electric heaters and ovens

Hydrocarbon and non-hydrocarbon fires can be detected

Rugged, leak-proof, heat-sealed, acid-resistant, and with an injection molded polypropylene housing

120° wide field of view

Digital communication via RS-485 interface

FirePic™; The digital flame signal is marked with time and date

Built-in detector performs self-test automatically

The unit model design can realize independent operation
