F7133 4通道配电模块 HIMA

【产品详情】

输入电压：24VDC

功耗：最大3.5W

通讯接口：RS485、以太网

工作温度：-40°C 至 +70°C

防护等级：IP20

产品参数

尺寸：140 毫米 x 120 毫米 x 40 毫米

重量：0.5公斤

H51X的4通道配电，H51q用于扩展机架F-基本机架11，包括小型保险丝5×20，4 A-T，H

数字输出可用于检测短路和开路输入，例如符合Cat的紧急停止按钮。4按照EN 954-1的说法。为此，输出为脉冲输出，并连接到同一设备的安全相关数字输入，参见第3.1.1章。这种情况下，数字输出承担脉冲输出的功能。

致动器上无续流二极管时，可连接感性负载。然而，HIMA强烈建议将保护二极管直接连接到执行器上。故障时的反应如果设备在数字输出上检测到故障信号，受影响的模块输出将使用安全开关设置为安全(断电)状态。如果设备出现故障，所有数字输出都将关闭。在这两种情况下，设备都会激活故障LED。错误代码允许用户在用户程序中配置额外的故障反应。

F7133 4通道配电模块 HIMA

【英文介绍】

Input voltage: 24VDC

Power consumption: Maximum 3.5W

Communication interface: RS485, Ethernet

Operating temperature: -40°C to +70°C

Protection level: IP20

Product parameter

Dimensions: 140 mm x 120 mm x 40 mm

Weight: 0.5 kg

H51X 4-channel power distribution, H51q for expansion rack F-base rack 11, including small fuse 5× 20,4 A-T, H

Digital outputs can be used to detect short and open circuit inputs, such as a CAT-compliant emergency stop button. 4 According to EN 954-1. For this purpose, the output is a pulse output and is connected to a safety-related digital input of the same device, see Chapter 3.1.1. In this case, the digital output assumes the function of the pulse output.

The inductive load can be connected when there is no continuous current diode on the actuator. However, HIMA strongly recommends that the protective diode be connected directly to the actuator. If the device detects a fault signal on the digital output, the affected module output will be set to a safe (power off) state using a safety switch. If the device fails, all digital outputs are turned off. In both cases, the device activates the faulty LED. Error codes allow the user to configure additional fault responses in the user program.

F7133 4通道配电模块 HIMA
