FCP280 RH924YA 现场控制处理器 支持四个PIO通道

【产品详情】

可选的双电缆底板支持四个PIO通道，但提供单独的A / B总线连接器以及用于可选时间频闪输入的专用连接器。

从可选的双电缆底板到标准或紧凑型200系列FBM的现场总线连接需要单独的A / B总线电缆以及FBM底板(RH926KW)上的双“D”连接适配器。

FCP280可支持的fbm数量因所使用的fbm类型而异:

•仅与FCP280一起使用的200系列fbm – FCP280底板上的每个现场总线端口可以通过2 Mbps的HDLC现场总线连接到底板链，每条链最多可连接32个紧凑型或标准200系列fbm，最多可连接128个模块。

•与FCP280配合使用的200系列和100系列fbm(双波特配置)。

FCP280可以在一个或多个基板链中支持总共128个100系列fbm (y模块)或竞争设备(如Foxboro DCS系统迁移fbm)，剩余的128个模块限制为200系列fbm，具体取决于FCP280的现场总线负载。例如，FCP280可以支持64个100系列fbm和64个200系列fbm

FBMs(64 + 64 = 128)。为了计数目的，主fbm和扩展fbm被视为两个fbm。同样，每个PIO总线/底板端口上不允许超过64个100系列fbm。请看下面两个图。

FCP280RH924YA现场控制处理器280（FCP280）是一款高性能、高可靠性的工业自动化控制系统中的核心组件。它通常用于实现现场设备的控制、监测和数据采集等功能。

FCP280RH924YA现场控制处理器280（FCP280）具有以下特点：

高性能：采用先进的处理器和算法，能够快速、准确地处理各种控制任务和数据采集任务。

高可靠性：采用工业级的设计和制造标准，能够适应各种恶劣的工作环境，保证系统的稳定性和可靠性。

易于编程：提供丰富的编程接口和开发工具，方便用户进行程序开发和调试。

易于扩展：支持多种通信协议和接口，方便与其他设备或系统进行连接和扩展。

如果您需要了解更多关于FCP280RH924YA现场控制处理器280（FCP280）的详细信息，建议您参考施耐德电气的官方网站或联系其技术支持团队。

FCP280 RH924YA 现场控制处理器 支持四个PIO通道

【英文介绍】

The optional dual cable baseplate supports four PIO channels, but provides separate A/B bus connectors as well as dedicated connectors for optional time strobe inputs.

Fieldbus connections from the optional dual cable baseplate to the standard or compact 200 series FBM require A separate A/B bus cable as well as a dual "D" connection adapter on the FBM baseplate (RH926KW).

The number of FBMS that the FCP280 can support varies depending on the type of fbm used:

200 Series fbm for use only with FCP280 - Each fieldbus port on the FCP280 baseboard can be connected to the baseboard chain via a 2 Mbps HDLC fieldbus, and each chain can connect up to 32 compact or standard 200 series fbm for up to 128 modules.

200 series and 100 Series fbm(dual baud configuration) for use with the FCP280.

The FCP280 can support a total of 128 100 series FBMS (y modules) or competing devices (such as Foxboro DCS system migration FBMS) in one or more substrate chains, with the remaining 128 modules limited to 200 series FBMS, depending on the fieldbus load of the FCP280. For example, the FCP280 can support 64 100 series FBMS and 64 200 series FBMS

FBMs(64 + 64 = 128). For counting purposes, the main fbm and the extended fbm are treated as two FBMS. Similarly, no more than 64 100 series FBMS are allowed on each PIO bus/backplane port. Take a look at the following two figures.

The FCP280RH924YA Field Control Processor 280 (FCP280) is the core component of a high-performance, highly reliable industrial automation control system. It is usually used to realize the control, monitoring and data acquisition functions of field equipment.

The FCP280RH924YA Field Control Processor 280 (FCP280) has the following features:

High performance: Using advanced processors and algorithms, it can quickly and accurately handle various control tasks and data acquisition tasks.

High reliability: Industrial design and manufacturing standards are adopted, which can adapt to various harsh working environments to ensure the stability and reliability of the system.

Easy to program: Provide rich programming interfaces and development tools, convenient for users to develop and debug programs.

Easy to expand: Support a variety of communication protocols and interfaces, easy to connect and expand with other devices or systems.

If you need more information about the FCP280RH924YA Field Control Processor 280 (FCP280), please refer to Schneider Electric's official website or contact their technical support team.
