MMS6210  双通道轴位移测量模块 涡流位移传感器测量

【产品详情】

特点：

双通道轴位移测量模块，监测轴向位移、胀差。

可在运行中更换，可单独使用，冗余电源输入。

扩展的自检功能，内置传感器自检功能，口令保护操作级。

适用涡流传感器PR642./..系列加前置器CON0X1。

RS232/485端口用于现场组态及通讯，可读出测量值。

内置线性化处理器。

记录和存储近一次起/停机的测量数据。

应用：

双通道轴位移测量模块MMS6210测量轴的移动，如：轴向位移、胀差、热膨胀、径向轴位置。信号取自涡流位移传感器。

这种模块的测量可以和其它模块的测量一起组成涡轮机械保护系统, 或作为输入提供给分析诊断系统、现场总线系统、分散控制系统、电厂/主计算机、网络如：WAN/LAN网、以太网。

对于蒸汽机、燃汽机、水轮机、压缩机、风扇、离心机以及其它涡轮机械。使用本系统可提高使用效率、运行安全性和延长机械使用寿命。

MMS6210 为双通道轴位移测量模块，可以用涡流位移传感器测量轴向移动来监测和保护各种类型的涡轮机械，如：汽轮机、燃汽轮机、压缩机、风扇、齿轮箱、鼓风机、离心机等。

传感器的输出，即模块的输入代表传感器前端到被测物表面的间隙。信号经过MMS6210模块处理并与设置的工作模式成正比转换成标准信号输出。模块的其它部分提供报警、传感器供电、模块供电、通道和传感器的检测及信号滤波等功能。

内置微处理器，可以通过现场便携机或远程通讯总线设置工作方式和参数、读取所有测量值。

后一次起/停机过程存储在模块中，可以通过计算机显示。

MMS6210  双通道轴位移测量模块 涡流位移传感器测量

【英文介绍】

Features:

Dual channel axial displacement measurement module, monitoring axial displacement, expansion.

Can be replaced in operation, can be used alone, redundant power input.

Extended self-check function, built-in sensor self-check function, password protection operation level.

For eddy current sensor PR642./... Series plus preprocessor CON0X1.

RS232/485 port for field configuration and communication, can read the measured value.

Built-in linearization processor.

Record and store measurement data for the last start/stop.

Applications:

The dual channel axis displacement measurement module MMS6210 measures axis movement, such as axial displacement, differential expansion, thermal expansion, and radial axis position. The signal is taken from a vortex displacement sensor.

Measurements of this module can be combined with measurements of other modules to form a turbomachinery protection system, or provided as input to an analytical diagnostic system, fieldbus system, decentralized control system, power plant/main computer, network such as WAN/LAN network, Ethernet.

For steam engines, gas engines, water turbines, compressors, fans, centrifuges and other turbo-machinery. Using this system can improve the efficiency, operation safety and prolong the service life of the machine.

The MMS6210 is a two-channel axial displacement measurement module that can be used to measure axial movement with eddy current displacement sensors to monitor and protect various types of turbine-machinery such as steam turbines, gas turbines, compressors, fans, gearboxes, blowers, centrifuges, etc.

The output of the sensor, the input of the module, represents the gap between the front end of the sensor and the surface of the object being measured. The signal is processed by the MMS6210 module and converted into a standard signal output in direct proportion to the set working mode. Other parts of the module provide alarm, sensor power supply, module power supply, channel and sensor detection and signal filtering functions.

The built-in microprocessor allows you to set the working mode and parameters and read all the measured values from the field portable computer or the remote communication bus.

The last start up/stop procedure is stored in the module and can be displayed through the computer.
