MMS6823 RS485 EPRO 转换模块  通讯接口模块

【产品详情】

特点：

RS485输入

数据输出方式：

-    MODBUS RTU/ASCII

-    以太网TCP/IP

两种总线输出方式并行，相互间不影响。

MODBUS总线的输出方式RTU/ASCII可任选。

可传输特征值，模块波形数据，以及模块状态和报警状态等物理量。

19”框架用标准卡件。

模块可通过TCP/IP接口对各板件进行组态。

键相信号调整功能。

冗余电源输入。

应用：

通讯接口模块MMS6823的功能是通过RS485总线不断地访问连接在总线上的MMS6000模块，同时将接收到的特征值数据和报警及模块状态数据转换成标准Modbus协议，Modbus输出可以选择MODBUS RTU或MODBUS ASCII协议方式。并将接收到的特征值数据和报警及模块状态数据转换成标准TCP/IP协议，可通过以太网RJ45 接口输出。这些数据可以被与之相连的振动分析系统或DCS、DEH等系统访问并调用显示。

通过MMS6823可对连接的MMS6000模块进行组态设置。RS485总线和MODBUS 输出是通过模块后面的48芯插座连接的，TCP/IP网络接口为标准RJ45 接口，位于模块的后面板上，使用标准网络电缆连接。MMS6823的IP地址可以根据需要灵活设置。

MMS6823 RS485 EPRO 转换模块  通讯接口模块

【英文介绍】

Features:

RS485 input

Data output mode:

-    MODBUS RTU/ASCII

- Ethernet TCP/IP

The two bus output modes are parallel and do not affect each other.

MODBUS Output mode RTU/ASCII Optional.

It can transmit characteristic values, module waveform data, and physical quantities such as module status and alarm status.

Standard card for 19 "frame.

The module can configure each board through the TCP/IP interface.

Key key adjustment function.

Redundant power input.

Applications:

The function of the communication interface module MMS6823 is to continuously access the MMS6000 module connected to the bus through the RS485 bus, and convert the received characteristic value data, alarm and module status data into the standard Modbus protocol. Modbus output can be MODBUS RTU or MODBUS ASCII protocol. The received eigenvalue data and alarm and module status data are converted into standard TCP/IP protocol, which can be output through Ethernet RJ45 interface. These data can be accessed and displayed by connected vibration analysis systems or DCS, DEH and other systems.

The MMS6823 allows you to configure the connected MMS6000 module. The RS485 bus and MODBUS output are connected via a 48-pin socket at the back of the module, and the TCP/IP network interface is a standard RJ45 port located on the rear panel of the module and connected using a standard network cable. The IP address of the MMS6823 can be flexibly set as required.
