MMS6350 EPRC 转速测量模块 测量轴的转速

【产品详情】

   MMS6350转速测量模块的测量可以和其它模块的测量一起组成涡轮机械保护系统, 以及作为输入提供给分析诊断系统、现场总线系统、分散控制系统、电厂/主计算机、网络如：WAN/LAN网、局域网。对于蒸汽机、燃汽机、水轮机、压缩机、风扇、离心机以及其它涡轮机械，使用本系统可提高使用效率、运行*性和延长机械使用寿命。

应用

转速测量模块 MMS6350测量轴的转速, 使用触发齿轮及脉冲传感器产生的输出。

两个通道可以独立使用,可用于测量：

－ 两个轴的转速；

－ 两个轴的零转速；

－ 两个轴的键相脉冲信号，每个轴一个键相触发标识，用以描述相位；

－ 在使用多齿触发齿轮时，按每转输出一个脉冲的模式(与相位无关)得到两个轴 的键相脉冲信号。

两个通道可以结合起来使用：

－ 监测一个轴的旋转方向；

－ 监测两个轴的速度差值；

－ 作为多通道或冗余系统的一部分。

MMS6350 EPRC 转速测量模块 测量轴的转速

【英文介绍】

Measurements from the MMS6350 speed measurement module can be combined with measurements from other modules to form turbine-machine protection systems, as well as provided as input to analytical diagnostic systems, fieldbus systems, decentralized control systems, power plants/main computers, networks such as WAN/LAN networks, local area networks. For steam engines, gas engines, water turbines, compressors, fans, centrifuges and other turbo-machinery, the use of this system can improve the use efficiency, operation efficiency and prolong the service life of the machinery.

Apply

The speed measurement module MMS6350 measures the speed of the shaft, using the output generated by the trigger gear and pulse sensor.

Two channels can be used independently and can be used for measurement:

- Speed of both axes;

- Zero speed of both axes;

- The key phase pulse signal of two axes, one key phase trigger identifier for each axis, to describe the phase;

- When using multi-tooth trigger gear, press the mode of output pulse per revolution (independent of phase) to get the key phase pulse signal of two axes.

Two channels can be used in combination:

- Monitoring the direction of rotation of an axis;

- Monitor the speed difference between the two axes;

- As part of a multi-channel or redundant system.
