Emerson  1C31194G01 阀门定位器控制模块 检测电路

【产品详情】

艾默生过程管理，西屋公司 Ovation

目录描述： 阀门定位器控制模块

备选部件号： Westinghouse 1C31194G01

常见印刷错误： IC31194G01， 1C31194GO1

1C31194G01数字输入模块包含16个通道，每个通道都有电压电平检测电路，用于检测输入是打开还是关闭。该模块是提供 16 个隔离差分输入或 16 个单端（公共返回）数字输入，带有卡上熔断器检测功能，用于辅助电源。这个性化模块的选择决定了 1C31194G01 的输入是差分还是单端。模块监控的输入电压电平由模块中的特定卡组。单端配置的磁场侧电路如图10-1所示以及图 10-2 中的差分配置。输入电阻器提供正常模式浪涌保护，并限制正常工作期间的电流。一光隔离器在场侧和逻辑之间提供高 1C31194G01 介电隔离或 I/O 总线侧。

Emerson是技术与工程领域的全球领袖,在商业、工业和消费者市场中为全世界的客户开发并提供创新的解决方案。主要经销: Emerson ovation西

屋1C311,1C312,1X00,5X00系列，Deltav德尔塔夫，EPRO系列传感器前置器VE3008、CE3008 、SE3008、 VE3007, SE4006P2等.OVATION系统是艾默生旗下的一个产品，属于DCS控制系统，产地泰国，主要致力与火力发电，钢铁，石油、化工等行业，有通讯稳定，抗干扰能力强的特点。

Emerson  1C31194G01 阀门定位器控制模块 检测电路

【英文介绍】

Emerson Process Management, Westinghouse Ovation

Catalog description: Valve positioner control module

Alternative Part number: Westinghouse 1C31194G01

Common typographical errors: IC31194G01, 1C31194GO1

The 1C31194G01 digital input module contains 16 channels, each with a voltage level detection circuit to detect whether the input is on or off. The module is designed to provide 16 isolated differential inputs or 16 single-ended (common return) digital inputs with on-card fuse detection for auxiliary power. The choice of this personalization module determines whether the input to 1C31194G01 is differential or single-ended. The input voltage level monitored by the module is determined by the specific card group in the module. Figure 10-1 shows the magnetic field side circuit in single-ended configuration and the differential configuration in Figure 10-2. Input resistors provide normal mode surge protection and limit current during normal operation. An optical isolator provides a high 1C31194G01 dielectric isolation or I/O bus side between the field side and the logic side.

Emerson is a global leader in technology and engineering, developing and delivering innovative solutions to customers around the world in commercial, industrial and consumer markets. Main distribution: Emerson ovation West

House 1C311,1C312,1X00,5X00 series, Deltav DeltaV, EPRO series sensor preprocessor VE3008, CE3008, SE3008, VE3007, SE4006P2, etc. OVATION system is a product of Emerson, belongs to DCS control system, origin in Thailand, mainly committed to thermal power generation, steel, petroleum, chemical and other industries, with stable communication, strong anti-interference ability characteristics.
