1 Type of Company

Where MR Is a relay type, MT is a transistor type, their difference is:

1. The external power supply connected with the electric appliance can be DC power supply or AC power supply, which can directly drive 220v DC load. The external power supply of the transistor can only connect direct current, not directly drive the switch

2. The switching frequency of the relay is low, and the high-frequency signals such as the pulse output of the system can be output using the transistor PLC. Select the corresponding PLC specifications according to the needs in practical applications.

2PLC output

Output terminal introduction

Take 40 terminals as an example, 3 groups of input +2 groups of output =5 x 40 terminals, in which the input terminal has only one common terminal S/S, and the output terminal has five common terminals. Y2, Y3 share con2,Y4, y5, y6, y7 share com3, Y10, y11, y12, y13 share com4,Y14, y15, y16, y17 share com5.

3 Relay Wiring

Relay PLC output circuit is shown in the following figure. Dc and AC power supplies can be used to drive the load regardless of drain-source output.

Relay type PLC output loop

Common output controls in industrial control include motor, indicator light, alarm, solenoid valve, etc. Some can be directly connected with the PLC output terminal Y, and some need intermediate relay or contactor connection.
