☆型号:IC755CSW07CDA-AE 人机界面 (HMI) 支持面板安装或 VESA 75 安装的 HMI 设备
【产品详情】
品牌 GE发那科
系列 快速面板
制造者: GE发那科
制造者 艾默生自动化/GE Fanuc(前身)
零件编号 IC755CSW07CDA
产品系列: 快速面板+
该IC755CSW07CDA是艾默生自动化的 QuickPanel+ 操作终端。该设备通常被业内大多数人员称为人机界面 (HMI) 或操作员界面终端 (OIT),因为该电子设备主要用于通过分辨率为 800 x 480 像素的嵌入式 7 英寸宽屏显示器和多点触控操作员输入界面,提供所连接机器或过程的实时监控和控制功能。此外,该终端还能够用作控制器、机器网关和数据历史数据库。
IC755CSW07CDA 是支持面板安装或 VESA 75 安装的 HMI 设备。它需要 +24VDC ±20% 的输入电源电压端接到提供的 3 针 Phoenix 型连接器。该设备的最大功耗为 15 瓦。它使用自然对流进行设备冷却,并且必须安装在温度范围为 0-55 摄氏度且相对湿度为 85% 的应用区域。
IC755CSW07CDA预安装了 Windows Compact Embedded 7 操作系统 (OS) 的实例。该操作系统提供用户友好的配置环境,并提供连接功能和终端管理功能和工具。此HMI安装Intel Freescale i.MX535 1 GHz ARM Cortex A8处理器,集成内存,由512 MB DDR2 SDRAM、256 MB SLC NAND闪存和512 KB SRAM组成。
该 HMI 提供一 (1) 个以太网 I/P 通信端口和一 (1) 个 RS232 通信接口。它还具有三 (3) 个 USB 端口和一 (1) 个用于内存扩展的 SD SDHC 可移动卡插槽。
IC755CSW07CDA端子是GE发那科制造的7英寸Quickpanel端子。它是Quickpanel系列终端,具有彩色TFT宽屏,可以显示清晰的数据和信息。面板支持多点触控,使用方便。它的分辨率为 WVGA 800 x 480 像素。它由 24 伏直流电源供电。终端采用GE交织字母表圈。该终端采用 NEMA 4X 外壳设计。它配备了 512 MB DDR2 SDRAM 和 256 MB NAND 闪存用于存储。IC755CSW07CDA 终端具有单个 10/100 Base T 以太网端口和一个用于通信的 RS-232 端口。显示终端中还存在两个 USB 端口。温度应保持在 0 到 55 摄氏度之间,以获得最佳运行效果。操作界面终端已通过 UL、CE 和 EN 标准认证。
GE Fanuc IC755CSW07CDA 终端搭载 ARM A8 皮层处理器,速度为 1 GHz。它能够轻松处理 2D 和 3D 图形。该终端配备了 NEON SIMD 媒体加速器,有助于处理图形密集型流程。另一个 Vector 浮点协处理器也用于处理逻辑运算。终端使用 Windows 7 操作系统与操作员对接。IC755CSW07CDA端子的最大额定功耗为 15 瓦。采用自然对流法来维持终端的温度。不使用时,它可以存放在 -10 到 60 摄氏度之间的温度中。
【英文介绍】
Brand GE Fanuc
Series quick panel
Manufacturer: GE Fanuc
Manufacturer Emerson Automation /GE Fanuc (predecessor)
Part number IC755CSW07CDA
Product line: Fast panel +
The IC755CSW07CDA is Emerson Automation's QuickPanel+ operator terminal. The device is often referred to by most in the industry as the Human Machine Interface (HMI) or Operator interface terminal (OIT) because the electronic device is primarily used to provide real-time monitoring and control of the connected machine or process through an embedded 7-inch widescreen display with a resolution of 800 x 480 pixels and a multi-touch operator input interface. In addition, the terminal can be used as a controller, machine gateway, and data history database.
The IC755CSW07CDA is an HMI device that supports panel mounting or VESA 75 mounting. It requires +24VDC ±20% of the input supply voltage to be terminated to the provided 3-pin Phoenix connector. The device has a maximum power consumption of 15 watts. It uses natural convection for device cooling and must be installed in an application area with a temperature range of 0-55 degrees Celsius and a relative humidity of 85%.
The IC755CSW07CDA is preinstalled with an instance of Windows Compact Embedded 7 operating system (OS). The operating system provides a user-friendly configuration environment and provides connectivity and terminal management functions and tools. This HMI is equipped with an Intel Freescale i.MX535 1 GHz ARM Cortex A8 processor with integrated memory consisting of 512 MB DDR2 SDRAM, 256 MB SLC NAND flash memory, and 512 KB SRAM.
The HMI provides one (1) Ethernet I/P communication port and one (1) RS232 communication interface. It also has three (3) USB ports and one (1) SD SDHC removable card slot for memory expansion.
The IC755CSW07CDA terminal is a 7-inch Quickpanel terminal manufactured by GE Fanuc. It is a Quickpanel series terminal with a color TFT widescreen screen that can display clear data and information. Panel support multi-touch, easy to use. Its resolution is WVGA 800 x 480 pixels. It is powered by a 24 volt DC supply. The terminal uses GE interweaving alphabet circles. The terminal features a NEMA 4X housing design. It comes with 512 MB DDR2 SDRAM and 256 MB NAND flash memory for storage. The IC755CSW07CDA terminal has a single 10/100 Base T Ethernet port and an RS-232 port for communication. There are also two USB ports in the display terminal. The temperature should be kept between 0 and 55 degrees Celsius for optimal operation. The terminal has passed the UL, CE, and EN standards.
The GE Fanuc IC755CSW07CDA terminal is powered by an ARM A8 cortex processor at 1 GHz. It can easily handle 2D and 3D graphics. The terminal is equipped with a NEON SIMD media accelerator to help handle graphics-intensive processes. Another Vector floating-point coprocessor is also used to handle logical operations. The terminal uses the Windows 7 operating system to connect to the operator. The IC755CSW07CDA terminal has a maximum rated power consumption of 15 watts. Natural convection is used to maintain the terminal temperature. When not in use, it can be stored at temperatures between -10 and 60 degrees Celsius.
