1769-L35E 数字量 I/O 模块

【产品详情】

Bulletin 1769 Compact I/O™ 基于机架的模块可用作 1769 CompactLogix™ L3x、CompactLogix 5370 或 Compact GuardLogix® 5370 控制器的本地和分布式 I/O。无机架设计中的机架类型特性降低了成本，并可减少可更换部件库存。内置的可拆卸端子块提供了与 I/O 传感器和执行机构的连接。

提供 DIN 导轨或面板安装选项，使用灵活

包括各点诊断状态指示灯，方便了故障处理

可通过软件钥匙来防止模块的错误定位

最多可向控制器连接三组 Compact I/O™；需要使用通信适配器模块和电源）

1769 Compact 数字量 I/O 模块

提供各种交流和直流电压

每个模块包括 8 - 32 点

包括触点输出模块

包括高速输入模块

提供输入滤波

提供光电隔离

1769 Compact 模拟量 I/O 模块

提供模拟量、热电偶和热电阻模块

提供高精度等级

包括过量程或欠量程检测和指示

包括板载整定

向断线的输入传感器提供可选择的响应

能够在异常情况下引导输出设备操作

提供单独配置通道

可对输入进行自动校准

1769-AENTR I/O 模块

支持符合 EtherNet/IP TCP/CIP 连接 96 的单网络策略

为 DLR 和线形拓扑提供双以太网端口

通过 EtherNet/IP 上的分布式 I/O 简化系统架构

通过重新利用现有的 1769 I/O 进行控制移植

I/O 包速率为 10,000 pps

可进行直接连接

1769 Compact 特殊功能 I/O 模块

提供地址预留、ASCII、布尔控制和高速计数器模块

通过 Compact I/O™ 到 DPI/SCANport™ 和 Compact I/O 到DSI/Modbus 模块，将 1769 平台直接连接到 PowerFlex® 驱动器和其他设备

我们的集成架构解决方案为有效推动全厂最优化奠定基础，让您能够积极应对经济状况以及消费需求的变化。

我们的 PartnerNetwork™ 通过 Encompass 产品引荐计划为 1769 Compact I/O 模块和 1769 CompactLogix 用户自定义配置文件提供互补产品解决方案。您可以对所在地区中的业内最佳供应商的产品进行排序和筛选，进而与 Rockwell Automation® 架构连接，或者与我们的产品结合使用。

1769-L35E 数字量 I/O 模块

【英文介绍】

Bulletin 1769 Compact I/O™ rack-based modules are available locally and distributed for 1769 CompactLogix™ L3x, CompactLogix 5370 or Compact GuardLogix® 5370 controllers I/O. Rack type features in rackless designs reduce costs and reduce replaceable parts inventory. The built-in detachable terminal block provides connection to the I/O sensor and actuator.

DIN rail or panel mounting options are available for flexible use

Includes diagnostic status indicators for each point, facilitating troubleshooting

Incorrect positioning of the module can be prevented by the software key

Up to three sets of Compact I/O™ can be connected to the controller; Requires the use of communication adapter modules and power supplies)

1769 Compact Digital I/O module

Various AC and DC voltages are available

Each module consists of 8-32 points

Includes contact output module

Includes high speed input module

Provide input filtering

Provide photoelectric isolation

1769 Compact Analog I/O module

Analog, thermocouple and thermal resistance modules are available

High precision grades available

Includes over - or under-range detection and indication

Including onboard setting

Provides an optional response to the disconnected input sensor

Ability to guide output device operation in abnormal conditions

Provides a separate configuration channel

The input can be automatically calibrated

1769-AENTR I/O module

Supports a single network policy that complies with EtherNet/IP TCP/CIP connection 96

Dual Ethernet ports for DLR and line topology

Simplify system architecture with distributed I/O over EtherNet/IP

Control migration by repurposing existing 1769 I/O

The I/O packet rate is 10,000 pps

Direct connection possible

1769 Compact Special Function I/O module

Address reservation, ASCII, Boolean control and high speed counter modules are available

Connect the 1769 platform directly to PowerFlex® drives and other devices via Compact I/O™ to DPI/SCANport™ and Compact I/O to DSI/Modbus modules

Our integrated architecture solutions lay the foundation for effective factory-wide optimisation, enabling you to respond to changes in economic conditions and consumer demand.

Our PartnerNetwork™ provides complementary product solutions for the 1769 Compact I/O module and the 1769 CompactLogix User-Defined profile through the Encompass Product Referral Program. You can sort and filter products from the industry's best suppliers in your region to connect with the Rockwell Automation® architecture or use them in conjunction with our products.
