2711P-T7C22D9P 模拟电阻式触摸屏 图形终端

【产品详情】

2711P-T7C22D9P的技术参数

制造者 罗克韦尔自动化

品牌 艾伦-布拉德利

显示区域： 132 x 99 毫米（5.2 x 3.9）

显示类型： 彩色有源矩阵TFT LCD

操作力： 100 克

驱动额定值： 100万台印刷机

触摸屏： 模拟电阻式触摸屏

操作员输入： 触摸

Allen-Bradley 2711P-T7C22D9P 是一款功能强大的图形终端，是 PanelView Plus 7 产品线的一部分。它有一个 6.5 英寸显示屏尺寸的触摸屏输入。2711P-T7C22D9P 还配备了 TFT 彩色显示屏和触摸输入。在高效的SD卡的配合下，该图形终端可快速复制和恢复操作界面。它具有 LED 背光和 24 伏直流电的输入电压要求。虽然背光是不可改变的，但在 50,000 摄氏度（40 华氏度）和 50% 亮度下，其使用寿命至少可达 50 小时。

2711P-T7C22D9P 的触摸屏显示器是模拟电阻式的。其驱动额定值约为 100 万次压力，操作力高达 100 克。2711P-T7C22D9P 的显示分辨率为 640 x 480 VGA，带有 18 位彩色图形。它支持（cat.Number） 1784-SDx 卡，并具有高达 512 MB RAM 和 512 MB 存储的系统内存。此外，该终端还促进了用于网络连接的单个或 DLR 以太网端口。其功耗最大为 50 瓦（2.1 伏直流电时为 24 A）。

2711P-T7C22D9P 是一款 6.5 英寸彩色薄膜晶体管 （TFT） 屏幕。凭借这种屏幕尺寸，这款高性能终端非常适合简单和小型应用，因为它的可视区域仅为 132 x 99 毫米或 5.2 x 3.9 英寸，显示分辨率为 640 x 480 SVGA、18 位和支持。它支持 18 位彩色图形，允许它通过颜色编码设计显示静态和动态图形。这样可以提高信息水平，有助于更有效、更准确的控制。通过触摸输入界面，操作员可以获得舒适的输入界面，因为触摸屏机制允许直接与运行时对象进行交互，而无需参考外部键盘。使用戴手套的手指或手写笔以 100 g 的驱动力操作触摸屏界面是理想的选择。

作为高性能终端，2711P-T7C22D9P 配备两 （2） 个以太网接口，支持线性、设备级环网 （DLR） 和星形拓扑。这主要用于通信和集成驻留在自动化设备内存中的数据。该高性能终端兼容 Allen-Bradley Logix 控制器以及 SLC500 和 MicroLogix 等较旧的控制器。这些端口还可用于将 HMI 集成为工厂级和企业自动化组件的一部分。它支持 10/100 Mbps 传输速度和自动协商功能，可以使用中继器设备或媒体转换器设备进行扩展。

2711P-T7C22D9P 模拟电阻式触摸屏 图形终端

【英文介绍】

Technical parameters of 2711P-T7C22D9P

Manufacturer Rockwell Automation

Brand Allen Bradley

Display area: 132 x 99 mm (5.2 x 3.9)

Display type: Color active Matrix TFT LCD

Operating force: 100g

Drive rating: 1 million presses

Touch screen: Analog resistive touch screen

Operator input: Touch

The Allen-Bradley 2711P-T7C22D9P is a powerful graphics terminal that is part of the PanelView Plus 7 product line. It has a touchscreen input in the size of a 6.5-inch display. The 2711P-T7C22D9P also comes with a TFT color display and touch input. With an efficient SD card, the graphics terminal can quickly copy and recover the operating interface. It has LED backlight and 24 VDC input voltage requirements. Although the backlight is immutable, it has a lifetime of at least 50 hours at 50,000 degrees Celsius (40 degrees Fahrenheit) and 50 percent brightness.

The touch screen display of the 2711P-T7C22D9P is analog resistive. Its drive rating is about 1 million times of pressure, and the operating force is up to 100 grams. The 2711P-T7C22D9P has a display resolution of 640 x 480 VGA with 18-bit color graphics. It supports (cat.Number) 1784-SDx cards and has system memory of up to 512 MB of RAM and 512 MB of storage. In addition, the terminal facilitates a single or DLR Ethernet port for network connectivity. Its power consumption is up to 50 watts (24 A at 2.1 volts DC).

The 2711P-T7C22D9P is a 6.5-inch color thin-film transistor (TFT) screen. With this screen size, this high-performance terminal is ideal for simple and small applications, as it has a viewing area of only 132 x 99 mm or 5.2 x 3.9 inches and a display resolution of 640 x 480 SVGA, 18 bits and support. It supports 18-bit color graphics, allowing it to display both static and dynamic graphics through color-coded designs. This can increase the level of information and contribute to more effective and accurate control. By touching the input interface, the operator gets a comfortable input interface because the touch screen mechanism allows direct interaction with runtime objects without having to refer to an external keyboard. Using gloved fingers or a stylus to operate the touchscreen interface with 100 g of driving force is ideal.

As a high-performance terminal, the 2711P-T7C22D9P is equipped with two (2) Ethernet interfaces and supports linear, device-level ring network (DLR) and star topologies. This is primarily used for communication and integration of data residing in the automation device's memory. This high-performance terminal is compatible with Allen-Bradley Logix controllers as well as older controllers such as the SLC500 and MicroLogix. These ports can also be used to integrate the HMI as part of factory-level and enterprise automation components. It supports 10/100 Mbps transfer speeds and auto-negotiation capabilities, and can be extended with repeater devices or media converter devices.

2711P-T7C22D9P 模拟电阻式触摸屏 图形终端
