1756-OV16E 数字直流输出模块 具有 16 个灌电流和电子熔断输出
【产品详情】
1756-OV16E 的技术参数
制造者 罗克韦尔自动化
品牌 艾伦-布拉德利
零件号/目录号 1756-OV16E型
系列 ControlLogix
模块类型 电子熔丝灌电流输出模块
输出 16 点电子熔断器
电压 12-24 伏直流灌电流
工作电压范围 10-30 伏直流电
最大输出电流额定点 60 摄氏度时为 1 安培
最大输出电流额定值-模块 60 摄氏度时为 8 安培
功耗(最大值) 60 摄氏度时为 6.72 瓦
5 V 时的背板电流 210毫安
可拆卸接线端子 1756-TBNH,1756-TBSH
隔离电压 50 伏连续电压
外壳 没有
刚果爱国者联盟 10612598264367
关于1756-OV16E
Allen-Bradley 的 1756-OV16E ControlLogix 数字直流输出模块是 ControlLogix 数字直流输出模块系列中的一个输出模块,具有 16 个灌电流和电子熔断输出,位于 1756 ControlLogix 设备的机箱插槽中。它的先导额定值为 1A (DC-13/SR),额定工作电压为 10-30V DC。1756-OV16E的标称信号延迟时间为75μs(OFF至ON状态)和360μs(ON至OFF状态),OFF至ON和ON至OFF的最大延迟时间为1ms。它的背板额定值分别为 2mA (5.1V) 和 210mA (24V) 以及 1.12W 的总功率。在OFF状态下,1756-OV16E电路的最大功耗为6.72W,每个点的最大漏电流为1mA。1756-OV16E 每个输出点的最大电流
为 1A,模块上的总电流为 8A,在 60 °C 时为 8A。 每个点上的最低电流负载为 2mA,每 2 秒重复一次 2A 浪涌,持续 10ms。1756-OV16E的绝缘电压为250V,采用基本绝缘类型,在输出到背板和输出组到组之间在1350V AC下常规测试2s。它具有 IEC 指定的 T4 温度代码和北美 T4 温度代码,并且采用开放式外壳。1756-OV16E 在 0-60 °C 和 5-95% 非冷凝湿度下运行最佳。
1756-OV16E 数字直流输出模块 具有 16 个灌电流和电子熔断输出
【英文介绍】
Technical parameters of 1756-OV16E
Manufacturer Rockwell Automation
Brand Allen Bradley
Part Number/Catalog number 1756-OV16E Model
Series ControlLogix
Module Type Electronic fuse filling current output module
Output 16 point electronic fuse
Voltage 12-24 volts DC irrigation current
Operating voltage range 10-30 volts DC
The maximum output current is 1 amp at the rated point of 60 degrees Celsius
Maximum output current rating - 8 amps at 60 degrees Celsius for the module
Power consumption (Max) 6.72 watts at 60 degrees Celsius
The backplane current at 5 V is 210 mA
Detachable terminal 1756-TBNH, 1756-TBSH
Isolation voltage 50 V continuous voltage
Shell no
Union of Congolese Patriots 10612598264367
About 1756-OV16E
Allen-Bradley's 1756-OV16E ControlLogix digital DC output module is an output module in the ControlLogix digital DC output module family, with 16 filling current and electronic fuse outputs. Located in the chassis slot of the 1756 ControlLogix device. It has a pilot rating of 1A (DC-13/SR) and a rated operating voltage of 10-30V DC. The 1756-OV16E has a nominal signal delay time of 75μs (OFF to ON) and 360μs (ON to OFF), with a maximum delay time of 1ms for OFF to ON and ON to OFF. It has backplane ratings of 2mA (5.1V) and 210mA (24V), respectively, and 1.12W of total power. In the OFF state, the 1756-OV16E circuit has a maximum power consumption of 6.72W and a maximum leakage current of 1mA at each point. 1756-OV16E Maximum current at each output point
Is 1A, the total current on the module is 8A, 8A at 60 °C. The minimum current load at each point is 2mA, with a 2A surge repeated every 2 seconds for 10ms. The 1756-OV16E has an insulation voltage of 250V, with a basic insulation type that routinely tests 2s at 1350V AC between output to backplane and output group to group. It has an IEC specified T4 temperature code and a North American T4 temperature code, and is available in an open housing. The 1756-OV16E operates best at 0-60 °C and 5-95% non-condensing humidity.
