1756-M22 扩展内存模块   非易失性存储器模块

【产品详情】

Allen-Bradley 1756-M22 模块是用于 Allen-Bradley ControlLogix 5555 控制器的 750 KB 非易失性存储器模块。与 1756-M22 模块兼容的 ControlLogix 控制器包括 1756-L55、1756-L55M12、1756-L55M13、1756-L55M14、1756-L55M16、1756-L55M22、1756-L55M23 和 1756-L55M24 控制器。为防止损坏内存模块，在安装或更换内存模块之前，必须断开电池与控制器的连接。在 ControlLogix 5555 控制器上安装或更换 1756-M22 模块需要以下 4 个步骤：卸下控制器侧板、卸下现有内存板、安装新内存板和更换控制器侧板。标签可以放置在控制器的侧面，以标识所安装的内存板的类型。

1756-M22 模块对 ESD 敏感。为防止损坏模块，需要遵循以下预防措施：触摸接地物体以释放静电、佩戴接地腕带、避免触摸连接器或模块组件、使用防静电工作站以及将模块存放在防静电容器中。1756-M22 模块的工作温度范围为 0 至 60 摄氏度。该模块的存储温度范围为 -40 至 85 摄氏度。相对湿度范围为 5% 至 95%（非冷凝）。该模块的工作和非工作冲击额定值分别为 30 G 和 50 G。模块外壳打开，符合 T4 北美温度规范和 T4 IEC 温度规范。

1756-M22 扩展内存模块   非易失性存储器模块

【英文介绍】

The Allen-Bradley 1756-M22 module is a 750 KB non-volatile memory module for the Allen-Bradley ControlLogix 5555 controller. ControlLogix controllers compatible with the 1756-M22 module include 1756-L55, 1756-L55M12, 1756-L55M13, 1756-L55M14, 1756-L55M16, 1756-L55M22, 1756-L55M23, and 1756-L55M23 1756-L55M24 Controller. To prevent damage to the memory module, disconnect the battery from the controller before installing or replacing the memory module. Installing or replacing the 1756-M22 module on the ControlLogix 5555 controller requires the following four steps: Remove the controller side board, remove the existing memory board, install a new memory board, and replace the controller side board. Labels can be placed on the side of the controller to identify the type of memory board that is installed.

The 1756-M22 module is sensitive to ESD. To prevent module damage, take the following precautions: Touch grounding objects to release static electricity, wear a grounding wrist strap, avoid touching connectors or module components, use an ESD workstation, and store the module in an ESD container. The 1756-M22 module operates in a temperature range of 0 to 60 degrees Celsius. The module has a storage temperature range of -40 to 85 degrees Celsius. Relative humidity ranges from 5% to 95% (non-condensing). The module has a working and non-working impact rating of 30 G and 50 G respectively. The module housing opens to meet the T4 North American temperature specification and T4 IEC temperature specification.

1756-M22 扩展内存模块   非易失性存储器模块
