1756-M13 内存板 具有挥发性 具有开放式外壳

【产品详情】

1756-M13 内存板是 Allen-Bradley 制造的用于 A 系列 ControlLogix5555 控制器的内存板。其存储器大小为 1.5 兆字节，其静电放电抗扰度为间接接触放电的额定电压为 6 千伏，空气放电的额定抗扰度为 8 千伏。其排放等级为第1组，A类，具有挥发性。其抗机械冲击等级在不工作时为 50 G，在使用时为 30 G。该内存板的机械振动额定值为 2 G，频率为 10 至 500 赫兹，并具有开放式外壳。

此外，在安装 1756-M13 内存板并将其连接到控制器之前，必须断开输入电源和电池电源。ControlLogix5555 控制器前面板上的 OK 状态指示灯允许操作员或技术人员轻松验证内存模块是否正确安装。1756-M13 内存板的工作温度范围为 0 至 60 摄氏度，可在污染等级为 2 的工业环境中运行。连接 1756-M13 内存板时，控制器上可以使用 1756-BATM ControlLogix 电池模块。它适用于非冷凝相对湿度额定值为 5% 至 95% 的环境中的应用。不使用时，该模块可以存放在温度范围为 -40 至 85 摄氏度的环境中。

1756-M13 内存板 具有挥发性 具有开放式外壳

【英文介绍】

The 1756-M13 memory board is A memory board manufactured by Allen-Bradley for the A-Series ControlLogix5555 controller. Its memory size is 1.5 megabytes, and its electrostatic discharge immunity is rated at 6 kV for indirect contact discharge and 8 kV for air discharge. Its emission rating is Group 1, Class A, which is volatile. Its mechanical impact rating is 50 G when not working and 30 G when in use. The memory board has a mechanical vibration rating of 2 G, a frequency of 10 to 500 Hz, and an open housing.

In addition, the input power and battery power must be disconnected before installing the 1756-M13 memory board and connecting it to the controller. The OK status indicator on the ControlLogix5555 controller front panel allows the operator or technician to easily verify that the memory module is properly installed. The 1756-M13 memory board has an operating temperature range of 0 to 60 degrees Celsius and can operate in industrial environments with pollution level 2. When the 1756-M13 memory board is connected, the 1756-BATM ControlLogix battery module can be used on the controller. It is suitable for applications in environments with non-condensing relative humidity ratings ranging from 5% to 95%. When not in use, the module can be stored in a temperature range of -40 to 85 degrees Celsius.

1756-M13 内存板 具有挥发性 具有开放式外壳
