1756-M08SEG 接口模块 有 8 个可用轴
【产品详情】
Allen-Bradley 1756-M08SEG 是一个 SERCOS 接口模块,可以连接到符合扩展包配置文件的 SERCOS 接口驱动器。它有 8 个可用轴,但您只能为其使用 AXIS_GENERIC_DRIVE 数据类型。单个控制器最多可以使用 32 个轴。您只能在位置模式下控制驱动器,它具有 LED SERCOS 环形状态指示灯,可让您监控其当前状态。
1756-M08SEG 模块有两种可用的 SERCOS 数据速率,分别为 4 Mbps 和 8 Mbps。在 4Mbps 时,SERCOS 周期时间为0.5 ms(最多 2 个驱动器(Kinetix 6000 驱动器专用),1 ms(最多 4 个驱动器)和 2 ms(最多 8 个驱动器)。对于多达 4 个驱动器(也适用于 Kinetix 6000 驱动器),8 Mbps 时的 SERCOS 周期时间为 0.5 ms,对于最多 8 个驱动器为 1 ms,对于最多 16 个驱动器为 2 ms。
该模块的背板电流在 5V DC 时为 760 mA,在 24V DC 时为 2.5 mA。它还具有 5.1 W 的功耗。它在 0 到 60 摄氏度的温度下运行。它可以储存在 -40 至 85 摄氏度的温度下。1756-M08SEG 模块还具有 5% 至 95% 的非冷凝相对湿度。它还具有 2 g 在 10 至 500 Hz 时的振动、30 g 的工作冲击和 50 g 的非工作冲击。
1756-M08SEG 模块是基于机箱的模块,可以安装在任何可用的插槽中。在用光纤电缆线连接模块之前,安装电源和 ControlLogix 机箱并接地非常重要。电线很重要,因为它将模块与符合扩展包配置文件的驱动器连接起来,并且只有光纤电缆线与之兼容。与此模块兼容的 ControlLogix 机箱包括 1756-A4、1756-A7、1756-A10、1756-A13 和 1756-A17
1756-M08SEG 接口模块 有 8 个可用轴
【英文介绍】
Allen-Bradley 1756-M08SEG is a SERCOS interface module that can be connected to SERCOS interface drives that comply with the extension pack configuration file. It has eight axes available, but you can only use the AXIS_GENERIC_DRIVE data type for it. A single controller can use up to 32 axes. You can only control the drive in location mode and it has a LED SERCOS ring status indicator that allows you to monitor its current status.
The 1756-M08SEG module has two available SERCOS data rates of 4 Mbps and 8 Mbps. At 4Mbps, SERCOS cycle times are 0.5ms (up to 2 drives (dedicated to Kinetix 6000 drives), 1 ms (up to 4 drives) and 2 ms (up to 8 drives). The SERCOS cycle time is 0.5 ms at 8 Mbps for up to 4 drives (also for Kinetix 6000 drives), 1 ms for up to 8 drives, and 2 ms for up to 16 drives.
The backplane current of the module is 760 mA at 5V DC and 2.5 mA at 24V DC. It also has 5.1W power consumption. It operates at temperatures between 0 and 60 degrees Celsius. It can be stored at temperatures between -40 and 85 degrees Celsius. The 1756-M08SEG module also has a non-condensing relative humidity of 5% to 95%. It also has a vibration of 2 g at 10 to 500 Hz, a working shock of 30 g and a non-working shock of 50 g.
The 1756-M08SEG module is a chassis based module that can be installed in any available slot. It is important to install and ground the power supply and ControlLogix chassis before connecting the modules with fiber optic cable cables. The wire is important because it connects the module to the drive that conforms to the expansion pack profile and only the fiber optic cable is compatible with it. ControlLogix chassis compatible with this module include 1756-A4, 1756-A7, 1756-A10, 1756-A13, and 1756-A17
