1756-M08SE 串行实时通信系统接口模块

【产品详情】

Allen-Bradley 1756-M08SE 是一款 ControlLogix 模块。它是一个串行实时通信系统 （SERCOS） 接口模块，用于使 ControlLogix 机架能够直接与 SERCOS 驱动器连接。

1756-M08SE 支持集成多达八 （8） 个 Kinetix 驱动器，兼容不同 Kinetix 系列的各种驱动器，例如 2093 Kinetix 2000 多轴伺服驱动器、2094 Kinetix 6000 多轴伺服驱动器、2099 Kinetix 7000 大功率伺服驱动器和 2098 Ultra3000 SERCOS 伺服驱动器。1756-M08SE 能够以 4 Mbps 和 8 Mbps 的速度执行数据交换，并缩短周期时间，具体取决于数据速率和连接的驱动器数量。在 4 Mbps 数据速率下，周期时间包括 0.5 ms，最多 2 个驱动器;1 ms，最多 4 个驱动器和 2 ms，最多 8 个驱动器，而在 8 Mbps 时，循环时间为 0.5 ms，最多 4 个驱动器;1 毫秒，最多 8 个驱动器，2 毫秒，最多 16 个驱动器。该 SERCOS 可以配置为实现不同的驱动控制模式，例如位置、速度和扭矩。

1756-M08SE 直接安装在 1756 ControlLogix 机箱上。兼容机箱包括 1756-A4、1756-A7、1756-A10、1756-A13、1756-A17 以及标准和冗余电源，例如 1756-PA72/C、1756-PA75/B、1756-PB72/C、1756-PB75/B、1756-PC75/B、1756-PH75/B 和 1756-PA75R、1756-PB75R、1756-PSCA2。

用于 SERCOS 驱动器高速通信的兼容物理介质是目录号为 2090-SCEPxx-0 的塑料光纤电缆、无护套、氯化聚乙烯 2090-SCVPxx-0 标准护套、聚氯乙烯 2090-SCNPxx-0 尼龙护套和 2090-SCVGxx-0 标准护套、聚氯乙烯玻璃光缆。

1756-M08SE 串行实时通信系统接口模块

【英文介绍】

The Allen-Bradley 1756-M08SE is a ControlLogix module. It is a Serial Real-time Communication System (SERCOS) interface module that enables ControlLogix racks to connect directly to SERCOS drives.

The 1756-M08SE supports the integration of up to eight (8) Kinetix drives, compatible with various drives in different Kinetix series, Examples include 2093 Kinetix 2000 multi-axis servo drive, 2094 Kinetix 6000 multi-axis servo drive, 2099 Kinetix 7000 High power servo drive and 2098 Ultra3000 SERCOS servo drive. The 1756-M08SE is capable of performing data exchange at speeds of 4 Mbps and 8 Mbps and reduces cycle time, depending on the data rate and number of connected drives. At 4 Mbps data rate, cycle time includes 0.5 ms, up to 2 drives; 1 ms, up to 4 drives and 2 ms, up to 8 drives, while at 8 Mbps, the cycle time is 0.5 ms, up to 4 drives; 1 ms, up to 8 drives, 2 ms, up to 16 drives. The SERCOS can be configured to achieve different drive control modes, such as position, speed and torque.

The 1756-M08SE is installed directly in the 1756 ControlLogix chassis. Compatible chassis include 1756-A4, 1756-A7, 1756-A10, 1756-A13, 1756-A17 as well as standard and redundant power supplies, Examples include 1756-PA72/C, 1756-PA75/B, 1756-PB72/C, 1756-PB75/B, 1756-PC75/B, 1756-PH75/B, and 1756-PA75R, 1756-PB75R, 1756-PSCA2.

The compatible physical media for high-speed communication with SERCOS drivers are plastic fiber optic cable with catalog number 2090-SCEPxx-0, sheathless, chlorinated polyethylene 2090-SCVPxx-0 standard sheath-polyvinyl chloride 2090-SCNPxx-0 nylon sheath-2090-SCNPXX-0, and 2090-SCVGxx-0 Standard sheath, polyvinyl chloride glass cable.

1756-M08SE 串行实时通信系统接口模块
