Allen-Bradley 1756-L84EP 控制器模块

【产品详情】

1756-L84EP 模块是 Allen-Bradley 为其 ControlLogix 5580 系统设计的控制器模块。它支持 20 MB 的用户内存和总共 128,000 个 I/O。控制器支持的最大数字和模拟 I/O 数量分别为 128,000 和 4000。控制器附带一个容量为 2 GB 的 SD 卡，可用作额外的非易失性存储器。在 1.2 伏直流电下，1756-L84EP 消耗 5.0 毫安的电流，在 5.1 伏直流电下，控制器消耗 1.20 安培的电流。操作控制器的功耗为 6.2 瓦，操作控制器的热耗散为每小时 21.2 BTU。该控制器可与标准和冗余电源模块一起使用。控制器上的额定隔离度为 50 V，从 USB 到系统背板以及从以太网端口到系统背板。

1756-L84EP 控制器模块上的以太网端口到 USB 端口隔离已在 1000 伏电压下测试了 60 秒。1756-L84EP 模块的外壳是开放式的，重量约为 0.394 千克。USB 端口的推荐电线类别为 3，以太网端口的推荐电线类别为 2。USB 2.0 端口支持 12 Mbps 的数据传输速度，可用于控制器的编程和配置。1756-L84EP 模块可以安装在系统机箱的任何插槽中。1756-L84EP 模块的 ATEX 温度代码额定值为 T4。

Allen-Bradley 1756-L84EP 控制器模块

【英文介绍】

The 1756-L84EP module is a controller module designed by Allen-Bradley for their ControlLogix 5580 system. It supports 20 MB of user memory and a total of 128,000 I/ OS. The maximum number of digital and analog I/ OS supported by the controller is 128,000 and 4000 respectively. The controller comes with an SD card with a capacity of 2 GB that can be used as additional non-volatile memory. At 1.2 volts DC, the 1756-L84EP consumes 5.0 milliamps, and at 5.1 volts DC, the controller consumes 1.20 amps. The power consumption of the operating controller is 6.2 watts and the heat dissipation of the operating controller is 21.2 BTU per hour. The controller can be used with standard and redundant power modules. The isolation rating on the controller is 50 V, from USB to the system backplane and from the Ethernet port to the system backplane.

Ethernet port to USB port isolation on the 1756-L84EP controller module has been tested for 60 seconds at 1000 volts. The 1756-L84EP module has an open housing and weighs approximately 0.394 kg. The recommended cable category for USB ports is 3, and the recommended cable category for Ethernet ports is 2. The USB 2.0 port supports data transfer speeds of 12 Mbps and can be used for programming and configuration of the controller. The 1756-L84EP module can be installed in any slot in the system chassis. The ATEX temperature code rating for the 1756-L84EP module is T4.

Allen-Bradley 1756-L84EP 控制器模块
