1756-L83EXT 控制器 可选非易失性内存容量

【产品详情】

1756-L83EXT 控制器是 ControlLogix-XT 5580 系列控制器的一部分制造的 ControlLogix-XT 控制器。本机配备 10 MB 标准用户内存和 2 GB 的可选非易失性内存容量。该控制器的电流消耗在 1.2 伏直流电下为 5.1 安培，在 1.2 伏直流电下为 5.0 毫安。它的额定功率为 6.2 W，散热额定值为每小时 21.2 BTU，背板的 USB 端口、以太网端口的基本绝缘型 USB 端口和背板的以太网端口具有 50 伏的连续隔离电压。它在 1000 伏交流电下测试 1 分钟。Allen-Bradley 1756-L83EXT 控制器的重量为 0.394 千克，模块位置基于机箱。它的工作温度范围为 -25 至 70 度，尤其是在 C 系列的 XT 机箱中。该控制器的非工作温度范围为 -40 至 85 摄氏度。

Allen-Bradley 1756-L83EXT ControlLogix-XT 5580 控制器对 C 系列的 XT 机箱的最高环境空气温度额定值为 70 摄氏度。控制器的可容忍相对湿度范围为 5% 至 95%，无冷凝，在 10 至 500 赫兹时，其最大额定振动为 2 g，在运行和断电时，其最大冲击额定值为 30 g。此控制器的外壳额定值为开放式额定值，USB 端口使用电线类别 3，以太网端口使用电线类别 2。1756-L83EXT ControlLogix-XT 5580 控制器已通过认证，符合 CSA、CE、RCM、Ex、IECEx、FM、cULus、KC 和 EAC 标准。它支持中继梯形图逻辑、结构化文本、顺序功能图和功能块图编程语言等编程语言。

1756-L83EXT 控制器 可选非易失性内存容量

【英文介绍】

The 1756-L83EXT controller is a ControlLogix-XT controller manufactured as part of the ControlLogix-XT 5580 series of controllers. The unit comes with 10 MB of standard user memory and 2 GB of optional non-volatile memory capacity. The current consumption of this controller is 5.1 amps at 1.2 volts DC and 5.0 MA at 1.2 volts DC. It has a power rating of 6.2 W, a heat dissipation rating of 21.2 BTU per hour, and a continuous isolation voltage of 50 volts for the USB port on the backplane, the basic insulated USB port on the Ethernet port, and the Ethernet port on the backplane. It is tested at 1000 volts AC for 1 minute. The Allen-Bradley 1756-L83EXT controller weighs 0.394 kg and the module position is based on the chassis. It operates in a temperature range of -25 to 70 degrees, especially in the CSeries XT chassis. The controller has a non-operating temperature range of -40 to 85 degrees Celsius.

The Allen-Bradley 1756-L83EXT ControlLogix-XT 5580 controller has a maximum ambient air temperature rating of 70 degrees Celsius for the XT chassis of the C Series. The controller has a tolerable relative humidity range of 5% to 95%, no condensation, a maximum vibration rating of 2 g at 10 to 500 Hz, and a maximum shock rating of 30 g during operation and power failure. The enclosure rating of this controller is open rated, and the USB port uses wire category 3 and the Ethernet port uses wire category 2. The 1756-L83EXT ControlLogix-XT 5580 controller is certified to comply with CSA, CE, RCM, Ex, IECEx, FM, cULus, KC and EAC standards. It supports programming languages such as relay ladder diagram logic, structured text, sequential function diagram, and function block diagram programming languages.

1756-L83EXT 控制器 可选非易失性内存容量
