1756-L83EP  处理器单元 EtherNet/IP 通信网络

【产品详情】

Allen-Bradley 1756-L83EP 处理器是基于 EtherNet/IP 通信网络的 ControlLogix 处理器单元。它带有 32 个任务，每个任务有 1000 个程序以及无限的事件触发器。该装置的数字 I/O 数量最多为 128,000 个 I/O，模拟 I/O 数量最多为 4000 个。该模块为用户提供 12 Mbps 的通信速度，并可选择支持 100 或 250 个以太网节点。1756-L83EP 处理器具有 10 MB 的用户内存容量和 50 伏的隔离电压（连续）。它的散热额定值为每小时 21.2 BTU，额定功率为 6.2 瓦。该装置在 5.1 伏时的电流消耗为 1.2 安培，在 5 伏直流电下的电流消耗为 1.2 毫安。

1756-L83EP 处理器还支持其他可选通信选项，包括 THE EtherNet、ControlNet、EtherNet/IP 和第三方选项，例如设备网络。对于以太网通信单元，用户必须考虑与控制器的连接以及输入和输出模块的连接。它们支持直接连接到 EtherNet/IP 网络，无需桥接模块。此控制器旨在与 SD 卡一起使用，因为这些卡已经过测试并确认与 1756-L83EP 处理器兼容并可用。它们还可以承受极端的工业温度水平。Allen-Bradley 1756-L83EP 处理器单元具有可选的非易失性存储存储单元，并配有 2 GB SD 卡。它有一个不可拆卸的能量存储。

1756-L83EP  处理器单元 EtherNet/IP 通信网络

【英文介绍】

The Allen-Bradley 1756-L83EP processor is a ControlLogix processor unit based on EtherNet/IP communication networks. It comes with 32 tasks, each with 1000 programs and an unlimited number of event triggers. The device has a maximum number of digital I/ OS of 128,000 and analog I/ OS of 4,000. The module provides users with a communication speed of 12 Mbps and the option to support 100 or 250 Ethernet nodes. The 1756-L83EP processor has 10 MB of user memory capacity and 50 volts of isolation (continuous). It has a heat dissipation rating of 21.2 BTU per hour and a power rating of 6.2 watts. The device has a current consumption of 1.2 amps at 5.1 volts and 1.2 mA at 5 volts DC.

THE 1756-L83EP processor also supports other optional communication options, including THE EtherNet, ControlNet, EtherNet/IP, and third-party options such as device networking. For the Ethernet communication unit, the user must consider the connection to the controller as well as the connection to the input and output modules. They support direct connection to EtherNet/IP networks without bridging modules. This controller is designed to be used with SD cards, as these cards have been tested and confirmed to be compatible and usable with the 1756-L83EP processor. They can also withstand extreme industrial temperature levels. The Allen-Bradley 1756-L83EP processor unit has an optional non-volatile storage storage unit and comes with a 2 GB SD card. It has a non-removable energy store.

1756-L83EP  处理器单元 EtherNet/IP 通信网络
