1756-L81EXT安全控制器 顺序功能图语言
【产品详情】
Allen-Bradley 1756-L81ES 控制器是 Allen-Bradley GuardLogix 5580 安全控制器。它可以执行 31 项标准任务和 1 项安全任务。每个任务支持的程序数为 1000 个程序。1756-L81ES 控制器上的集成通信端口包括一个 USB 端口和一个以太网端口。USB 端口符合 USB 2.0 标准,支持 12 Mbps 数据速率。以太网端口可以支持 10/100 和 1000 Mbps 的数据速率。1756-L81ES 控制器的可选通信模块包括 ControlNet、DeviceNet、远程 I/O、DH+ 和 SynchLink 模块。支持的最大以太网/IP 节点数为 100 个节点。
1756-L81ES 控制器支持以下编程语言:梯形图、结构化文本、功能块图和顺序功能图语言。不支持控制器冗余。模块上的用户内存容量为 3 MB,安全内存容量为 1.5 MB。支持的最大数字和模拟 I/O 数分别为 128,000 和 4000。1756-L81ES 控制器总共可支持 128,000 个 I/O。该模块带有 2 GB 的集成非易失性存储器。模块在 1.2 伏直流电下消耗的电流为 5 毫安,在 1.5 伏直流电下,电流消耗为 1.2 安培。运行期间作为热量耗散的功率为 6.2 瓦。模块重量约为 0.394 千克。1756-L81ES 控制器需要机箱中有一个空插槽进行安装。与 1756-L81ES 兼容的机箱包括 1756-A4、1756-A4K、1756-A7、1756-A7K、1756-A10、1756-A10K、1756-A13、1756-A13K、1756-A17 以及 1756-A17 K B 系列和 C 系列机箱。工作温度范围为 0 至 60 摄氏度。
Allen-Bradley 1756-L81ES 是一款 GuardLogix 控制器,具有 3 MB 的集成用户内存和 1.5 MB 的安全内存,与 ControlLogix 控制器类似,该控制器的最大 I/O 容量为 128,000。它具有USB和以太网的集成通信端口。
与 ControlLogix 控制器不同,此 GuardLogix 控制器具有 1756-SD2 的集成可移动内存,这是此控制器模块的唯一兼容内存。
该模块支持更多种类的机箱。虽然这是一个 GuardLogix 控制器,但它可以安装在标准和随形 ControlLogix 机箱中,例如 1756-A4、1756-A4K、1756-A7、1756-A7K、1756-A10、1756-A10K、1756-A13、1756-A13K、1756-A17、1756-A17 K 系列 B、C 系列。它还可以与更广泛的电源模块一起使用,例如 1756-PA50、1756-PA72、1756-PA72K、1756-PA75、1756-PA75K、1756-PB50、1756-PB72、1756-PB72K、1756-PB75、1756-PB75K、1756-PH75、1756-PC75。
该模块支持使用 ControlLogix 冗余模块实现冗余。对于此高可用性要求,兼容的电源为 1756-PA75R、1756-PA75RK、1756-PB75R、1756-PB75RK、1756-PSCA2、1756-PSCA2K。
它具有直观的诊断显示屏,可提供模块状态的文本描述。
使用此控制器,可达到安全仪表等级 (SIL) 2。该模块支持标准 ControlLogix 和安全 I/O 的混合,还可以实现标准 ControlLogix 可以支持的拓扑结构。
1756-L81EXT安全控制器 顺序功能图语言
【英文介绍】
The Allen-Bradley 1756-L81ES controller is the Allen-Bradley GuardLogix 5580 safety controller. It can perform 31 standard tasks and 1 security task. Each task supports 1000 programs. Integrated communication ports on the 1756-L81ES controller include a USB port and an Ethernet port. The USB port is USB 2.0 compliant and supports a 12 Mbps data rate. Ethernet ports can support data rates of 10/100 and 1000 Mbps. Optional communication modules for the 1756-L81ES controller include ControlNet, DeviceNet, Remote I/O, DH+, and SynchLink modules. The maximum number of Ethernet /IP nodes supported is 100.
The 1756-L81ES controller supports the following programming languages: ladder diagram, structured text, function block diagram and sequential function diagram languages. Controller redundancy is not supported. The user memory capacity on the module is 3 MB and the safe memory capacity is 1.5 MB. The maximum number of digital and analog I/ OS supported is 128,000 and 4000 respectively. The 1756-L81ES controller can support a total of 128,000 I/ OS. The module comes with 2 GB of integrated non-volatile memory. The module consumes 5 mA at 1.2 volts DC and 1.2 amps at 1.5 volts DC. The power dissipated as heat during operation is 6.2 watts. The module weighs approximately 0.394 kg. The 1756-L81ES controller requires an empty slot in the chassis for installation. Chassis compatible with the 1756-L81ES include the 1756-A4, 1756-A4K, 1756-A7, 1756-A7K, 1756-A10, 1756-A10K, 1756-A13, 1756-A13K, 1756-A17, and 1756-A17 K B Series and C Series chassis. Operating temperature range is 0 to 60 degrees Celsius.
The Allen-Bradley 1756-L81ES is a GuardLogix controller with 3 MB of integrated user memory and 1.5 MB of safe memory, similar to the ControlLogix controller, which has a maximum I/O capacity of 128,000. It has integrated communication ports for USB and Ethernet.
Unlike the ControlLogix controller, this GuardLogix controller has 1756-SD2 integrated removable memory, which is the only compatible memory for this controller module.
This module supports a wider range of chassis. Although this is a GuardLogix controller, it can be installed in standard and random ControlLogix cases, For example, 1756-A4, 1756-A4K, 1756-A7, 1756-A7K, 1756-A10, 1756-A10K, 1756-A13, 1756-A13K, 1756-A17, 1756-A17 K series B, C series. It can also be used with a wider range of power modules, Such as 1756-PA50, 1756-PA72, 1756-PA72K, 1756-PA75, 1756-PA75K, 1756-PB50, 1756-PB72, 1756-PB72K, 1756-PB75, 1756-PB75, 1756-PH75, 1756-P C75.
This module supports redundancy using the ControlLogix redundancy module. For this high availability requirement, compatible power supplies are 1756-PA75R, 1756-PA75RK, 1756-PB75R, 1756-PB75RK, 1756-PSCA2, 1756-PSCA2K.
It has an intuitive diagnostic display that provides a text description of the status of the module.
With this controller, Safety Instrument Class (SIL) 2 is achieved. This module supports a mix of standard ControlLogix and secure I/O, and can also implement topologies that standard ControlLogix can support.
