1756-L55M22 控制器 接收数据并与 I/O 通信

【产品详情】

Allen-Bradley 1756-L55M22 是一款 ControlLogix 控制器，是 Logix5000 系列控制器的成员。它具有 750 KB 的数据和逻辑存储器、208 KB 的 I/O 存储器以及集成的非易失性备份存储器。1756-L55M22 有 2 个 CPU，一个 Logix 和一个背板，它们在它们之间分配资源。应用程序代码和消息由 Logix CPU 执行，背板 CPU 从背板发送和接收数据并与 I/O 通信。

1756-L55M22 控制器通过串行端口连接到工作站或其他控制器。1756-CP3 串行电缆用于将控制器连接到工作站。为了与其他设备进行通信，它使用各种网络，如以太网/IP、ControlNet、DeviceNet 等。1756-L55M22 可以通过 EtherNet/IP 或 ControlNet 网络生成和使用系统共享标签。生产者和消费者系统各需要一个连接。

1756-L55M22 控制器具有多任务处理功能，可将处理时间分配给应用中的不同操作。它还包含用于组数据和逻辑的程序。它提供了用一种编程语言封装可执行代码的例程。它支持在线和离线的 Logix5000 编程语言。如果发生任何 I/O 通信故障，它有一个闪烁绿色的 I/O LED。它还包含用于诊断的故障处理程序。1756-L55M22 支持 1756-BA1 或 1756-BATM 电池，需要定期维护。

1756-L55M22 控制器 接收数据并与 I/O 通信

【英文介绍】

The Allen-Bradley 1756-L55M22 is a ControlLogix controller that is a member of the Logix5000 family of controllers. It has 750 KB of data and logic memory, 208 KB of I/O memory, and integrated non-volatile backup memory. The 1756-L55M22 has 2 cpus, a Logix and a backplane, which distribute resources between them. Application code and messages are executed by the Logix CPU, from which the backplane CPU sends and receives data and communicates with I/O.

The 1756-L55M22 controller is connected to a workstation or other controller via a serial port. The 1756-CP3 serial cable is used to connect the controller to the workstation. In order to communicate with other devices, it uses various networks such as Ethernet /IP, ControlNet, DeviceNet, etc. The 1756-L55M22 can generate and use system share tags over EtherNet/IP or ControlNet networks. The producer and consumer systems each require a connection.

The 1756-L55M22 controller has multi-tasking capabilities to allocate processing time to different operations in the application. It also contains programs for grouping data and logic. It provides routines that encapsulate executable code in a programming language. It supports both online and offline Logix5000 programming language. If any I/O communication failure occurs, it has a blinking green I/O LED. It also contains a fault handler for diagnosis. The 1756-L55M22 supports 1756-BA1 or 1756-BATM batteries and requires regular maintenance.

1756-L55M22 控制器 接收数据并与 I/O 通信
