1771-NC6 连接远程终端面板 电缆

【产品详情】

Allen-Bradley 1771-NC6是一种用于连接远程终端面板或rtp到Allen-Bradley 1771-N系列模拟模块的电缆。Allen-Bradley 1771-N模块用于与Allen-Bradley PLC-3, PLC-5和Allen-Bradley PLC-5/250可编程控制器一起工作，当模块和可编程控制器通过电缆如1771-NC6电缆连接时。1771-N模块专为需要高分辨率和良好抗噪性的应用而设计。这些模块使用16位模数转换器和14位数模转换器来实现所需的分辨率和精度。n系列模块经过设计和测试，可在所有通道之间提供1000V隔离，确保一个通道上的噪声信号，电压瞬变或短路/过载不会影响任何其他通道。每年需要校准一次，可以通过PLC处理器进行校准。

1771-N系列模块设计用于与带有1771-NC6电缆的远程终端面板(rtp)结合使用。输入/输出接线端接在RTP现场接线连接器上，预制电缆(如1771-NC6)用于将RTP连接到1771-N I/O模块以进行操作。1771-NC6是一根6英尺(1.8米)长的电缆，用于将rtp连接到1771-N I/O模块，以创建更大、更高效的机械系统。1771-NC6线缆两端分别连接25pin连接器。1771-N模块有4通道和8通道两种配置。将相关rtp (1771-RTP1, 1771-RTP2, 1771-RTP4)与8通道I/O模块连接需要两根1771-NC6电缆，将相关rtp (1771-RT41, 1771-RT44)与4通道I/O模块连接只需要一根1771-NC6电缆。

1771-NC6 连接远程终端面板 电缆

【英文介绍】

Allen-Bradley 1771-NC6 is a cable for connecting remote terminal panels or rtp to Allen-Bradley 1771-N series analog modules. The Allen-Bradley 1771-N module is used to work with Allen-Bradley PLC-3, PLC-5, and Allen-Bradley PLC-5/250 programmable controllers when the module and programmable controller are connected via a cable such as the 1771-NC6 cable. The 1771-N module is designed for applications that require high resolution and good noise resistance. These modules use 16-bit analog-to-digital converters and 14-bit analog-to-digital converters to achieve the required resolution and precision. The N-Series modules are designed and tested to provide 1000V isolation between all channels, ensuring that noisy signals, voltage transients or short circuits/overloads on one channel do not affect any other channels. It needs to be calibrated once a year and can be calibrated by a PLC processor.

The 1771-N series modules are designed for use with Remote Terminal Panels (rtp) with 1771-NC6 cables. The input/output wiring is terminated on the RTP field wiring connector, and prefabricated cables (such as the 1771-NC6) are used to connect the RTP to the 1771-N I/O module for operation. The 1771-NC6 is a 6-foot (1.8 m) cable used to connect the rtp to the 1771-N I/O module to create a larger, more efficient mechanical system. Connect both ends of the 1771-NC6 cable to 25pin connectors. The 1771-N module is available in 4 - and 8-channel configurations. Connecting the relevant rtp (1771-RTP1, 1771-RTP2, 1771-RTP4) to the 8-channel I/O module requires two 1771-NC6 cables, Connecting the relevant rtp (1771-RT41, 1771-RT44) to a 4-channel I/O module requires only one 1771-NC6 cable.
