1771-IVN 数字直流输入模块 逻辑电平

【产品详情】

Allen-Bradley 1771-IVN是PLC 5数字直流输入模块。它将用户设备提供的直流信号转换为处理器所需的逻辑电平。直接控制PLC数据表中相应位的状态。它提供了一种模块化设计，具有节省空间和口袋友好的方式来添加PLC控制系统的输入。它有一个1771-WN的接线臂来取代模块，省去了拆线的需要。1771-IVN是一个系列C模块，支持½和1槽I/O寻址。它在Sink直流输入信号端接中有广泛的应用。

1771-IVN模块有32个(4组8个)输入，电压类别为10 - 60V直流源(吸收负载)。工作电压范围为直流10 - 30V。其典型信号延迟在On-DC状态下为6ms(±2)，Off-DC状态下为6ms(±2)。它的最大断开状态电流为1.7mA，背板电流负载为280mA。最大功耗15.6W，散热53.3 BTU/hr。1771- ivn安装在包含PLC处理器的1771 I/O机箱中。下连接器的引脚14和16以及上连接器的引脚30和32之间是用于将其放入右槽的键控带。

1771-IVN模块前面板有32个状态指示灯，用于系统逻辑侧指示。它具有光电隔离，以保护系统电路免受电瞬变的影响。1771-IVN还包含一个输入滤波功能，用于降低电气噪声。

1771-IVN 数字直流输入模块 逻辑电平

【英文介绍】

Allen-Bradley 1771-IVN is a PLC 5 digital DC input module. It converts the DC signal provided by the user device into the logic level required by the processor. Directly control the status of the corresponding bits in the PLC data table. It offers a modular design with a space-saving and pocket-friendly way to add input to the PLC control system. It has a 1771-WN wiring arm to replace the module, eliminating the need to remove wires. The 1771-IVN is a series C module that supports ½ and 1 slot I/O addressing. It is widely used in the terminal of Sink DC input signal.

The 1771-IVN module has 32 inputs (4 sets of 8) in the voltage class 10-60V DC source (absorbed load). The operating voltage range is 10-30V DC. The typical signal delay is 6ms(±2) at On-DC and 6ms(±2) at Off-DC. It has a maximum on-off current of 1.7mA and a backplane current load of 280mA. Maximum power consumption 15.6W, heat dissipation 53.3 BTU/hr. The 1771-IVN is installed in a 1771 I/O case containing a PLC processor. Between pins 14 and 16 of the lower connector and pins 30 and 32 of the upper connector are the keying bands used to put it into the right slot.

The front panel of the 1771-IVN module has 32 status indicators for the logical side of the system. It has photoelectric isolation to protect system circuits from electrical transients. The 1771-IVN also includes an input filtering function to reduce electrical noise.
