1762-IF4 具有4通道电流/电压模拟输入模块
【产品详情】
1762-IF4是Allen-Bradley MicroLogix 1200，具有4通道电流/电压模拟输入模块。它有一个Delta-Sigma转换器和4个差分(双极)输入。其模拟工作电压范围为-10至10伏直流正常电压和-10.5至10.5伏直流满量程。其模拟工作电流范围为4至20 mA正常和-21至21 mA满量程。该模块通过允许对系统进行额外的I/O，增强了MicroLogix的功能。它需要最小的间距，可以是DIN导轨或面板安装。模块通过1762总线接口在5 ~ 24伏直流电源上通信和接收信息。
当连接输入端子时，有一个手指安全罩。扁平带状电缆用于连接各种I/O模块。1762-IF4模块支持2线、3线或4线发送器配置。在故障排除过程中，用户应始终远离设备，并始终检查设备是否有任何程序更改。安全电路应该总是串联在主继电器上。
1762-IF4模块应安装在无危险、干燥、清洁的环境中，其电路不应越过II类过电压标准。为避免损坏模块，请务必防止静电放电并拔出电源。可现场升级的闪存操作系统有助于确保用户始终使用最新的功能，而无需更换任何硬件。I/O数量可以通过使用无机架I/O模块来扩展。这导致更大的控制系统，更大的应用灵活性和可扩展性，以更低的成本和减少零件库存。
该模块有四(4)个输入通道，每个输入通道可配置，可分别接收-21至21 mA和-10至+10VDC的电流和电压信号。
通过提供的拨码开关进行输入信号类型选择。接收到的电压信号通过模数转换器(ADC)将模拟数据转换为存储在模拟输入寄存器中的二进制代码。转换后的数据可以格式化为Raw / Proportional和Scale for PID。
如果与MicroLogix 1100一起使用，最多允许四(4)个扩展模块，可能是1764-IF4。如果安装MicroLogix 1200，可以连接6个级联模块，MicroLogix 1400可以连接7个级联模块。
1764-IF4等扩展模块通过提供的带状电缆连接到MicroLogix总线，该带状电缆由每个模块前面板上安装的引脚触点连接。本模块的安装遵循MicroLogix基础模块的安装方法，DIN导轨或直接面板安装。
该模块的尺寸为90mm(高)x 87mm(深)x 40mm(宽)，包括安装标签的高度为110mm 3.54 in。
1762-IF4 具有4通道电流/电压模拟输入模块
【英文介绍】
The 1762-IF4 is the Allen-Bradley MicroLogix 1200 with a 4-channel current/voltage analog input module. It has a Delta-Sigma converter and 4 differential (bipolar) inputs. Its analog operating voltage range is -10 to 10 volts DC normal voltage and -10.5 to 10.5 volts DC full scale. Its analog operating current ranges from 4 to 20 mA normal and -21 to 21 mA full scale. This module enhances the functionality of MicroLogix by allowing additional I/O to the system. It requires minimal spacing and can be DIN rail or panel mounted. The module communicates and receives information over a 5-24 volt DC power supply via a 1762 bus interface.
There is a finger safety cover when connecting the input terminals. Flat ribbon cables are used to connect various I/O modules. The 1762-IF4 module supports 2-, 3 -, or 4-wire transmitter configurations. During troubleshooting, the user should always stay away from the device and always check the device for any program changes. The safety circuit should always be connected in series to the main relay.
The 1762-IF4 module shall be installed in a non-hazardous, dry, clean environment, and its circuits shall not exceed Class II overvoltage standards. To avoid damage to the module, avoid electrostatic discharge and remove the power supply. The field-upgradeable flash operating system helps ensure that users are always using the latest features without having to replace any hardware. The amount of I/O can be expanded by using rackless I/O modules. This leads to larger control systems, greater application flexibility and scalability, at lower costs and reduced parts inventory.
The module has four (4) input channels, each configurable to receive current and voltage signals from -21 to 21 mA and -10 to +10VDC, respectively.
The input signal type is selected by the dip switch provided. The received voltage signal is converted by an analog-to-digital converter (ADC) into a binary code stored in an analog input register. The converted data can be formatted as Raw/Proportional and Scale for PID.
If used with MicroLogix 1100, up to four (4) extension modules are allowed, possibly 1764-IF4. If the MicroLogix 1200 is installed, six expansion modules can be connected, and the MicroLogix 1400 can be connected to seven expansion modules.
Expansion modules such as 1764-IF4 are connected to the MicroLogix bus via a supplied ribbon cable connected by pin contacts mounted on the front panel of each module. The installation of this module follows the installation method of the MicroLogix base module, DIN rail or direct panel mounting.
The module measures 90mm(H)x 87mm(D)x 40mm(W), with a height of 110mm 3.54 in including the mounting label.
