1756-DHRIO 数据高速公路/远程I-O通信模块
【产品详情】
Allen-Bradley 1756-DHRIO 是一款 ControlLogix Data Highway Plus/Remote I/O 通信接口模块。该模块有两 （2） 个通道，支持每秒 57.6 KB、每秒 115.2 KB 和每秒 230.4 KB 的通信速率，具体取决于电缆长度。它最多可以通过三个机箱和四个通信网络传输消息。使用此模块，可以在PLC，SLC和ControlLogix控制器等设备之间进行信息交换，甚至可以在不同的网络上进行。
它支持以下类型的通信：远程 I/O、控制和信息协议 （CIP） 消息传递以及设备之间的数据高速增强型 （DH+） 消息传递。它最多可以有 32 个 Logix 连接，远程 I/O 链路可以连接到远程 I/O 设备以及其他智能设备。当连接到远程 I/O 网络时，它可以充当适配器或扫描仪，即使在没有消息指令的情况下也能传输模拟、数字、块和专业数据。在安装 1756-DHRIO 模块之前，您需要为每个通道的网络类型交换机进行编程，并安装和连接 ControlLogix 电源和机箱。您可以在同一机箱中安装任意数量的模块，但这取决于您的可用电源。请注意，即使施加机箱电源，也可以安装或拆卸模块，但您需要遵守安全预防措施，特别是该区域是无害的并且电源已断开，以防止电弧导致模块和连接器的触点过度磨损。确保放电电位静电，因为模块对静电放电敏感。
RIO 和 DH+ 协议使用相同的电缆类型。推荐的电缆是百通 89463 双轴电缆，额定温度为 0 °C （52 °F） 的 20.200 mm² （392 AWG）。适用的备用连接器是凤凰端子，部件号 MVSTBR2.5/3-ST BK AU。
DH+ 和远程 I/O 网络需要使用终端电阻，因为它遵循菊花链拓扑。该电阻器安装在网络的第一个和最后一个节点。电阻值取决于网络速度。82欧姆用于230.4Kbps的网络速度。150 欧姆用于 57.6 Kbps 或 115.2 Kbps 的网络速度。还考虑了其他注意事项，包括连接到网络的设备类型。终端电阻安装在电缆的线路 1 和线路 2 上。第三根电缆是屏蔽电缆。
要按照RIO协议端接电缆，线路3连接到底部引脚或端子1，屏蔽电缆端接到中间引脚，线路1端接到最后一个引脚。要按照 DH+ 协议正确连接电缆，只需反转线路 2 和线路 1 的连接即可。
该模块支持与 Flex IO、POINT IO 系统的通信以及与 PLC 2、SLC、CompactLogix 和 ControlLogix 控制器的消息传递功能。
1756-DHRIO 数据高速公路/远程I-O通信模块
【英文介绍】
The Allen-Bradley 1756-DHRIO is a ControlLogix Data Highway Plus/Remote I/O communication interface module. The module has two (2) channels and supports communication rates of 57.6 kilobits per second, 115.2 kilobits per second and 230.4 kilobits per second, depending on cable length. It can transmit messages through up to three chassis and four communication networks. With this module, information can be exchanged between devices such as PLCS, SLCS and ControlLogix controllers, even on different networks.
It supports the following types of communication: remote I/O, Control and Information Protocol (CIP) messaging, and data High-speed Enhanced (DH+) messaging between devices. It can have up to 32 Logix connections, and remote I/O links can connect to remote I/O devices as well as other smart devices. When connected to a remote I/O network, it can act as an adapter or scanner, transferring analog, digital, block, and professional data even in the absence of message instructions. Before installing the 1756-DHRIO module, you will need to program the network type switches for each channel and install and connect the ControlLogix power supply and chassis. You can install any number of modules in the same chassis, but it depends on your available power supply. Please note that the module can be installed or removed even if a case power supply is applied, but you need to follow safety precautions, especially if the area is harmless and the power is disconnected, to prevent arcing from causing excessive wear on the contacts of the module and connector. Make sure the discharge potential is static because the module is sensitive to electrostatic discharge.
The RIO and DH+ protocols use the same cable type. The recommended cable is Belton 89463 two-axis cable, rated at 20.200 mm² (392 AWG) at 0 °C (52 °F). The suitable alternate connector is the Phoenix terminal, part number MVSTBR2.5/3-ST BK AU.
DH+ and remote I/O networks require the use of terminal resistors because it follows the Daisy chain topology. The resistor is installed at the first and last node of the network. The resistance value depends on the network speed. 82 ohms are used for a network speed of 230.4Kbps. 150 ohms are used for network speeds of 57.6Kbps or 115.2Kbps. Other considerations are also taken into account, including the type of device connected to the network. Terminal resistors are installed on lines 1 and 2 of the cable. The third cable is a shielded cable.
To end the cable according to the RIO protocol, line 3 is connected to the bottom pin or terminal 1, the shielded cable end is connected to the middle pin, and line 1 end is connected to the last pin. To properly connect the cable according to the DH+ protocol, simply reverse the connection of line 2 and line 1.
The module supports communication with Flex IO, POINT IO systems, and messaging with PLC 2, SLC, CompactLogix, and ControlLogix controllers.
1756-DHRIO 数据高速公路/远程I-O通信模块
【其他型号推荐】
| A-B | 1756-IB32 | A-B | 20-HIM-A6 | A-B | 1794-IB16 |
| A-B | 1756-IB32 | A-B | 2098-DSD-020X | A-B | 1794-ASB |
| A-B | 1769-L30ER | A-B | 1769-L33ER | A-B | 1747-L541 |
| A-B | 1762-L24BWA | A-B | 1794-AENT | A-B | 22B-D010N104 |
| A-B | 1756-OF8 | A-B | 1794-IE12 | A-B | 1756-PA72电源模块 |
| A-B | 2080-LC50-24QBB | A-B | 1794-OE12 | A-B | 1756-OF8模拟量模块 |
| A-B | 1769-L33ER | A-B | 1794-OB32P | A-B | 1756-IF16模拟量模块 |
| A-B | 1756-RM2 | A-B | 1794-IB32 | A-B | 1756-IB16数字量模块 |
| A-B | 1756-EN2TR | A-B | 1769-ECR . | A-B | 1756-EN2T通讯模块 |
| A-B | 1756-IB32 | A-B | 1769-L36ERMA | A-B | 1756-A7机架 |
| A-B | 1756-OB32 | A-B | 1756-IF16 | A-B | 1786-RPA/B |
| A-B | 1756-IF16 | A-B | 1756-IB32 | A-B | 1756-RM2 |
