1336F-BRF15-AA-EN 可调频率交流驱动器
【产品详情】
艾伦-布拉德利1336S-BRF15-AA-EN是一种可调频率交流驱动器。它是1336S PLUS系列的产品之一，旨在为三相感应电动机带来最佳的速度控制和软启动。它采用专利的无传感器矢量算法来实现这种控制。它的一大特点是能够同时提供交流和直流电压(380至480伏交流电压或513至620伏直流电压)。它只能控制不超过1.5马力(1.2千瓦)的小型电机。1336S-BRF15-AA-EN输出2.8安培电流。它带有IP20 (NEMA 1)外壳，因此您必须记住将此设备保护在具有更高IP等级的电气柜中。
艾伦-布拉德利1336S-BRF15-AA-EN提供了一个人机界面，显示易于编程和设备故障排除。该特性支持高级状态和故障报告。每次设备启动时，都会启动故障检查例程。该单位也有移动保护它免受浪涌。画框尺寸(画框A1尺寸)为215.9 x 290 x 160.0毫米(8.5 x 11.42 x 6.3英寸)。这件物品的重量约为4.31公斤(9.5磅)。这个交流驱动器是风扇冷却的。风扇位于驱动器的底部。它有助于保持驱动器的最佳温度。驱动器的环境温度应在0到40摄氏度之间波动。
1336F-BRF15-AA-EN 可调频率交流驱动器
【英文介绍】
The Allen-Bradley 1336S-BRF15-AA-EN is an Adjustable Frequency AC Drive. It is one of the products from the 1336S PLUS series built to bring optimal speed control and soft starting to three-phase induction motors. It uses patented sensorless vector algorithm to achieve this kind of control. One of its great features is the ability to be supplied both with AC and DC voltage (380 to 480 Volts AC or 513 to 620 Volts DC voltage). It can control only smaller-sized motors that do not produce more than 1.5 Horsepower (1.2kW). The 1336S-BRF15-AA-EN outputs 2.8 Amps current. It comes in an IP20 (NEMA 1) enclosure so you must keep in mind to protect this device inside of an electrical cabinet with higher IP rating.
The Allen-Bradley 1336S-BRF15-AA-EN provides an HMI with a display for easy programming and troubleshooting of the device. This feature supports premium status and fault reporting. Fault checking routines are initiated every time when the device is started. The unit also has MOVs to protect it against surges. The frame size dimensions (frame “A1” size) are 215.9 x 290 x 160.0 millimeters (8.5 x 11.42 x 6.3 inches). This item’s weight is approximated at 4.31 kilograms (9.5 pounds). This AC drive is fan cooled. The fan is located on the bottom side of the drive. It helps in keeping the drive’s temperature optimal. The ambient temperature of the drive should fluctuate between 0 to 40 degrees Celsius.
1336F-BRF15-AA-EN 可调频率交流驱动器
【其他型号推荐】
| A-B | 1756-IB32 | A-B | 20-HIM-A6 | A-B | 1794-IB16 |
| A-B | 1756-IB32 | A-B | 2098-DSD-020X | A-B | 1794-ASB |
| A-B | 1769-L30ER | A-B | 1769-L33ER | A-B | 1747-L541 |
| A-B | 1762-L24BWA | A-B | 1794-AENT | A-B | 22B-D010N104 |
| A-B | 1756-OF8 | A-B | 1794-IE12 | A-B | 1756-PA72电源模块 |
| A-B | 2080-LC50-24QBB | A-B | 1794-OE12 | A-B | 1756-OF8模拟量模块 |
| A-B | 1769-L33ER | A-B | 1794-OB32P | A-B | 1756-IF16模拟量模块 |
| A-B | 1756-RM2 | A-B | 1794-IB32 | A-B | 1756-IB16数字量模块 |
| A-B | 1756-EN2TR | A-B | 1769-ECR . | A-B | 1756-EN2T通讯模块 |
| A-B | 1756-IB32 | A-B | 1769-L36ERMA | A-B | 1756-A7机架 |
| A-B | 1756-OB32 | A-B | 1756-IF16 | A-B | 1786-RPA/B |
| A-B | 1756-IF16 | A-B | 1756-IB32 | A-B | 1756-RM2 |
