A-B MPL-B540K-SJ24AA /A 紧凑型伺服电机
【产品详情】
1)备件
2)保修期:12个月!
3)包装:原包装与纸箱。
4)交货时间:付款后3天内发货
5)所有货物将在发货前进行测试。
MPL-B540K-SJ24A这款罗克韦尔自动化165毫米MP低惯量交流电机是一款4000 RPM紧凑型伺服电机。它具有单转(hyperface协议)编码器反馈。如果需要制动,此交流同步伺服电机在电机中配有24 VDC制动器。此外,这款智能伺服配备圆形卡口电缆连接器,内置于此交流伺服电机上,额定电压为230V交流电。此MPL系列无刷电机还具有4英寸的长度。
Allen-Bradley的MPL-B540K-SJ24AA伺服电机是一款框架长度为165毫米的交流电机。其额定转速为4000转/分,属于Allen-Bradley公司的MPL系列。MPl系列的低惯量电机可支持高达8000 rpm的额定速度、0.16至18.6千瓦的输出功率、2.3至1440磅/英寸的连续失速扭矩和6.6至2460磅/英寸的峰值失速扭矩。MPL-B540K-SJ24AA伺服电机的输入额定值为400伏交流电。伺服电机的大约重量为33磅。额定输出功率为5.4千瓦。转子惯量为0.014 lb-in-s2。MPL-B540K-SJ24AA伺服电机的峰值和连续失速扭矩规格分别为420磅/英寸和172磅/英寸。
MPL-B540K-SJ24AA伺服电机的磁体堆叠长度为101.6毫米。对于反馈,伺服电机配有1024 sin/cos绝对值单圈编码器。该集成编码器支持Hiperface协议。其他伺服电机功能包括圆形卡口连接器、轴键、24伏直流制动器和IEC公制法兰。如果需要轴封,则需要从Allen-Bradley订购可选的密封套件。安装轴封的优点包括防止细颗粒和水分进入,减少电机轴承的磨损。轴封应使用轴封套件随附的润滑剂进行润滑。由于轴封容易磨损,因此建议定期检查。根据他们的情况,轴封的更换频率从3个月到12个月不等。第三方制造的轴封套件不应与Allen-Bradley马达一起使用。
A-B MPL-B540K-SJ24AA /A 紧凑型伺服电机
The MPL-B540K-SJ24A Rockwell Automation 165 mm MP low inertia AC motor is a 4000 RPM compact servo motor. It has single-turn (hyperface protocol) encoder feedback. If braking is required, this AC synchronous servo motor has a 24 VDC brake in the motor. In addition, the smart servo is equipped with a circular bayonet cable connector that is built into the AC servo motor with a rated voltage of 230V AC. This MPL series brushless motor also has a 4-inch length.
Allen-Bradley's MPL-B540K-SJ24AA servo motor is an AC motor with a frame length of 165 mm. It is rated at 4000 RPM and belongs to the Allen-Bradley MPL series. The low inertia motors of the MPl series support rated speeds of up to 8,000 rpm, output power of 0.16 to 18.6 kW, continuous stall torque of 2.3 to 1,440 LBS/inch, and peak stall torque of 6.6 to 2,460 LBS/inch. The input rating of the MPL-B540K-SJ24AA servo motor is 400 volts AC. The approximate weight of the servo motor is 33 pounds. The rated output power is 5.4 kW. The rotor inertia is 0.014 lb-in-s2. The MPL-B540K-SJ24AA servo motor has peak and continuous stall torque specifications of 420 lb/inch and 172 lb/inch, respectively.
The magnet stack length of the MPL-B540K-SJ24AA servo motor is 101.6 mm. For feedback, the servo motor is equipped with a 1024 sin/cos absolute single-turn encoder. The integrated encoder supports Hiperface protocol. Additional servomotor features include circular bayonet connectors, shaft keys, 24-volt DC brakes, and IEC metric flanges. If a shaft seal is required, an optional sealing kit will need to be ordered from Allen-Bradley. The advantages of installing shaft seals include preventing the entry of fine particles and moisture and reducing wear on motor bearings. The shaft seal should be lubricated with the lubricant that comes with the shaft seal kit. Since the shaft seal is prone to wear, regular inspection is recommended. Depending on their situation, the replacement frequency of shaft seals varies from 3 months to 12 months. Third party manufactured shaft seal kits should not be used with Allen-Bradley motors.
A-B MPL-B540K-SJ24AA /A 紧凑型伺服电机
