☆型号：2711P-T9W21D8S 操作终端 实现实时可视化和控制
【产品详情】
2711P-T9W21D8S 是一款 Allen-Bradley 操作终端，主要用作人机界面 （HMI） 设备，可在工厂车间实现实时可视化和控制。
2711P-T9W21D8S 是一款操作终端，是 PanelView Plus 7 Standard 操作终端的一部分。它配备了 9.0 英寸宽屏，18 位颜色的彩色显示屏，纵横比为 5：3，可视区域为 196 x 118 毫米，像素分辨率为 800 x 480 WVGA。它具有 300 尼特的典型亮度和不可更换的背光，设计用于在 50,000 小时的使用寿命下运行，最小温度为 40° C （104 °F） 至半亮度。
操作员交互通过模拟电阻式触摸屏界面输入，该接口在100克的操作力下具有100万次驱动额定值。它还配备了一个电池备份的实时时钟，每月精度为 +/-2 分钟，在 25 摄氏度下运行时，使用寿命为 4 年。该电池可更换，更换部件号为 2711P-RY2032。
2711P-T9W21D8S 带有两 （2） 个 USB 接口，允许插入 USB 闪存驱动器、USB 鼠标、USB 键盘、打印机和其他外部外围设备。它具有单个以太网通信端口，用于与可编程逻辑控制器 （PLC） 和可编程自动化控制器 （PAC） 交换数据。它具有集成的 512 MB RAM 和 512 MB 内部存储以及额外的 80 MB 用户内存。
☆型号：2711P-T9W21D8S 操作终端 实现实时可视化和控制
【英文介绍】
The 2711P-T9W21D8S is an Allen-Bradley operating terminal primarily used as a human machine interface (HMI) device for real-time visualization and control on the factory floor.
The 2711P-T9W21D8S is an operating terminal that is part of the PanelView Plus 7 Standard operating terminal. It features a 9.0-inch widescreen, 18-bit color display with an aspect ratio of 5:3, a viewing area of 196 x 118 mm, and a pixel resolution of 800 x 480 WVGA. It has a typical brightness of 300 nits and non-replaceable backlight, and is designed to operate at a service life of 50,000 hours, with a minimum temperature of 40° C (104 °F) to half brightness.
Operator interaction is input via an analog resistive touch screen interface with 1 million drive ratings at 100 grams of operating force. It also comes with a battery-backed real-time clock with an accuracy of +/-2 minutes per month and a service life of 4 years when operating at 25 degrees Celsius. The battery is replaceable and the replacement part number is 2711P-RY2032.
The 2711P-T9W21D8S comes with two (2) USB ports that allow the insertion of USB flash drives, USB mice, USB keyboards, printers, and other external peripherals. It has a single Ethernet communication port for exchanging data with programmable logic controllers (PLCS) and Programmable automation controllers (PACs). It has an integrated 512 MB of RAM and 512 MB of internal storage as well as an additional 80 MB of user memory.
