☆型号:2711-B5A8 操作终端 标准操作终端
【产品详情】
Allen-Bradley 的 2711-B5A8 操作终端是 PanelView 550,是 Bulletin 2711 PanelView 标准操作终端产品系列的一部分。该操作终端配备 5.5 英寸显示屏,分辨率为 256 x 128,显示面积为 120 x 60 毫米(4.75 x 2.38 英寸)。该操作终端具有两个通信端口,其中一个支持Data Highway Plus(DH+)和RS323,用于打印报警和系统消息。借助 Data Highway + (DH+),可以在单个节点中连接多达 32 个设备的菊花链,每个段的长度为 4000 m。它是一种令牌传递协议,允许连接到网络的节点通过 1770-CD 或 Belden 9463 通信电缆执行数据交换。
2711-B5A8 配有一个键盘组件,该键盘组件配有从 F1 到 F10 的十 (10) 个功能键,这些功能键完全可编程以适应所需的操作员操作。除此之外,这些键还可以分配全局或局部功能,从而允许按键在每个 HMI 窗口中具有可变功能或通用的固定分配,而不管当前显示的窗口如何。同样重要的是,该终端具有触摸感应界面,允许通过直接按下屏幕来操作设备。键盘和触摸屏最多可操作 100 万次。2711-B5A8 操作终端具有单色 LCD 蓝色模式显示屏,背光寿命为 100,000 小时。它的电源输入电压范围为 85-264V AC,频率为 47-63 Hz。它支持报警处理、屏幕安全、模拟仪表、用于扩展非易失性存储器的 ATA 存储卡。
过时的 2711-B5A8 PanelView 550 是一款旧的操作终端,允许用户与各种机器进行交互。该 Panelview 终端是一个人机界面或 HMI,具有 5.5 英寸。单色LCD蓝色模式屏幕。用户可以通过键盘和触摸屏来控制 2711-B5A8 装置,以输入信息和命令。
2711-B5A8 操作终端使用 120V 交流电源供电。2711-B5A8 单元具有 170 KB 的应用程序运行时内部存储器。该装置还具有内部背光更换部件号 2711-NL1。2711-B5A8 使用固态电子设备进行操作。请勿将其用作急停机构或任何其他类型的安全装置。2711-B5A8 PanelView 550 操作终端的运输重量和尺寸分别为 6 磅和 14 x 11 x 8 英寸。
☆型号:2711-B5A8 操作终端 标准操作终端
【英文介绍】
Allen-Bradley's 2711-B5A8 operating terminal is the PanelView 550, part of the Bulletin 2711 PanelView Standard operating terminal product family. The operating terminal features a 5.5-inch display with a resolution of 256 x 128 and a display area of 120 x 60 mm (4.75 x 2.38 inches). The operating terminal has two communication ports, one of which supports Data Highway Plus (DH+) and RS323 for printing alarm and system messages. With Data Highway + (DH+), daisy-chains of up to 32 devices can be connected in a single node, with each segment measuring 4000 m in length. It is a token passing protocol that allows nodes connected to a network to perform data exchange over a 1770-CD or Belden 9463 communication cable.
The 2711-B5A8 is equipped with a keyboard assembly with ten (10) function keys from F1 to F10 that are fully programmable to suit the desired operator operation. In addition to this, these keys can also be assigned global or local functions, allowing the keys to have variable functions or a common fixed assignment in each HMI window, regardless of the window currently displayed. Equally important, the terminal has a touch-sensitive interface that allows the device to be operated by directly pressing the screen. Keyboard and touch screen can be operated up to 1 million times. The 2711-B5A8 operating terminal features a monochrome LCD blue mode display with a backlight life of 100,000 hours. It has a power input voltage range of 85-264V AC and a frequency of 47-63 Hz. It supports alarm handling, screen security, analog meters, ATA memory cards for expanding non-volatile memory.
The obsolete 2711-B5A8 PanelView 550 is an older operating terminal that allows users to interact with a variety of machines. The Panelview terminal is a human machine interface or HMI with a 5.5 inch. Monochrome LCD blue mode screen. The 2711-B5A8 device can be controlled by the user through the keyboard and touch screen to enter information and commands.
2711-B5A8 Operating terminal uses 120V AC power supply. The 2711-B5A8 unit has 170 KB of internal application runtime memory. The unit also has an internal backlight replacement part number 2711-NL1. 2711-B5A8 operates with solid-state electronics. Do not use it as an emergency stop mechanism or any other type of safety device. The 2711-B5A8 PanelView 550 operating terminal has a shipping weight and dimensions of 6 pounds and 14 x 11 x 8 inches, respectively.
