MPL-B980C-MJ72AA 旋转伺服电机 具有创新的设计和高扭矩输出

☆型号：MPL-B980C-MJ72AA 旋转伺服电机 具有创新的设计和高扭矩输出

【产品详情】

MPL-B680H-MJ72AA 旋转伺服电机来自 Allen-Bradley/Rockwell Automation 的 MPL 系列。该伺服电机具有创新的设计和高扭矩输出。该伺服电机专为在恶劣的工业环境中使用而设计，与 Allen-Bradley Kinetix 5500 至 7000 伺服驱动器完全兼容。MPL-B680H-MJ72AA 伺服电机等伺服电机是带有 CE 标志的设备，它们符合 CSA 和 UL 标准等标准。该伺服电机采用智能电机技术，通过对特定应用至关重要的板载存储器帮助保留电机身份。该伺服电机的其他优点是由于使用稀土磁铁而加速更快，特殊的绕组绝缘材料可实现更好的热管理，以及用于安装的标准 IEC 72-1 尺寸。

MPL-B680H-MJ72AA 工业伺服电机提供高水平的性能，并具有反馈功能，包括一个输出值为 1024 正余弦的绝对多圈反馈编码器。MPL系列伺服电机提供其他反馈选项，用户可以根据需要进行选择。伺服电机的电压等级为 400 伏交流电，而其额定功率为 7.5 千瓦。值得一提的是，MPL-B680H-MJ72AA伺服电机的额定转速为2000转/分，可实现60至146.9牛米之间的失速转矩。除此之外，这种特殊伺服电机的转子惯量为每平方米 0.00775 千克。MPL-B680H-MJ72AA 伺服电机重约 40.4 千克（89 磅），配有无轴封的轴键、SpeedTec 圆形 DIN 连接器（直角）和出厂的基本控制选项。伺服电机的框架为 215 毫米，而其磁铁堆的长度为 203.2 毫米（8 英寸）。

☆型号：MPL-B980C-MJ72AA 旋转伺服电机 具有创新的设计和高扭矩输出

【英文介绍】

The MPL-B680H-MJ72AA rotary servo motor is from the Allen-Bradley/Rockwell Automation MPL series. The servo motor features an innovative design and high torque output. Designed for use in harsh industrial environments, the servo motor is fully compatible with Allen-Bradley Kinetix 5500 to 7000 servo drives. Servo motors such as MPL-B680H-MJ72AA servo motors are devices with the CE mark and they comply with standards such as CSA and UL standards. The servo motor uses smart motor technology to help preserve motor identity through on-board memory that is critical for specific applications. Other advantages of this servo motor are faster acceleration due to the use of rare earth magnets, special winding insulation for better thermal management, and standard IEC 72-1 dimensions for installation.

The MPL-B680H-MJ72AA industrial servo motor offers a high level of performance with feedback capabilities, including an absolute multi-turn feedback encoder with an output value of 1024 sine and cosine. The MPL series servomotors offer additional feedback options that users can choose according to their needs. The servo motor has a voltage class of 400 volts AC, while its rated power is 7.5 kilowatts. It is worth mentioning that the MPL-B680H-MJ72AA servo motor is rated at 2000 RPM and can achieve a stall torque between 60 and 146.9 nm. In addition, the rotor inertia of this special servo motor is 0.00775 kg per square meter. The MPL-B680H-MJ72AA servo motor weighs approximately 40.4 kg (89 lb) and comes with a sealless shaft key, SpeedTec circular DIN connector (right Angle) and factory basic control options. The frame of the servo motor is 215 mm, while the length of its magnet stack is 203.2 mm (8 inches).

☆型号：MPL-B980C-MJ72AA 旋转伺服电机 具有创新的设计和高扭矩输出
