2711P-T12C15D2 标准终端 提供了有效的接口

☆型号：2711P-T12C15D2 标准终端 提供了有效的接口

【产品详情】

Allen-Bradley 2711P-T12C15D2 PanelView Plus 1250 12.1 英寸标准终端是 Allen-Bradley PanelView Plus 系列 HMI 中的接口设备，它为机器提供了有效的接口，用于可视化、控制和维护。它具有紧凑的设计，具有模块化构建的组件，并且具有集成/基础配置单元，可以轻松设置并节省安装时间。2711P-T12C15D2 通过其 12.1 英寸彩色有源矩阵、带模拟触摸屏的 TFT LCD 和 300cd/m2 （尼特）的显示屏亮度提供可视化和输入。它的显示区域为 246 毫米 x 184 毫米（9.7 英寸 x 7.2 英寸），原始分辨率为 800 x 600 像素，并具有可现场更换的背光，待机时间约为 50,000 小时。它有一个紧凑型存储卡，用于内存扩展高达 512MB，并配有 1 个 RS-232 串行通信端口（用于文件传输、打印和逻辑控制器通信）、2 个 USB 端口（用于连接鼠标、键盘和打印机）、1 个基本配置的 10/100 Base T 以太网端口，并支持 ControlNet 通信模块。2711P-T12C15D2 采用直流供电，输入电压范围为 18 至 32V DC，标称 24V DC 时最大功耗为 70W，最大散热为 240 BTU/hr。它的工作温度范围为 32 至 131 华氏度，在 5% 至 95% 非冷凝相对湿度下，存储范围为 -13 至 158 华氏度，设计用于抵抗 15G 操作冲击，以及 57 至 500Hz 下的 2G 峰值振动。2711P-T12C15D2 采用 NEMA 12、13 和 4X 型室内外壳，并通过了 cUL-us、CE 和 C-TICK 认证。它重约 3.2 千克（7.1 磅），总运输尺寸为 282 毫米 x 363 毫米 x 55 毫米（11.12 英寸 x 14.30 英寸 x 2.18 英寸）。

Allen-Bradley 2711P-T12C15D2 是一款 PanelView Plus 操作终端。该操作终端是 PanelView Plus 1250 产品类别中专门的一部分，该产品类别特别具有 12.1 英寸彩色有源矩阵、带液晶显示器 （LCD） 的薄膜晶体管 （TFT）。它的屏幕分辨率为 800 x 600 像素，可用显示区域为 246 x 184 毫米（9.7 x 7.2 英寸）。该操作终端的可用输入界面为触摸界面，设计为在 10-110 g 的驱动力和 100 万次按压的预期驱动极限下操作。

该模块可用的嵌入式通信接口包括一 （1） 个 RS-232 串行接口，支持 DF1 和点对点 DH-485 通信协议;ControlNet 通信端口用于基于同轴的 Controlnet 通信协议和 RJ-45 用于以太网 I/P 通信协议。这种多样化的通信端口使该操作终端能够连接到传统、成熟和现代的工业网络中，而无需专用或附加通信模块和外围设备。

☆型号：2711P-T12C15D2 标准终端 提供了有效的接口

【英文介绍】

Allen-Bradley 2711P-T12C15D2 PanelView Plus 1250 12.1-inch standard terminal is an interface device in the Allen-Bradley PanelView Plus series HMI, which provides an effective interface to the machine. For visualization, control, and maintenance. It has a compact design with modular built components, and has an integrated/base configuration unit that is easy to set up and saves installation time. The 2711P-T12C15D2 provides visualization and input through its 12.1-inch color active matrix, TFT LCD with analog touch screen, and 300cd/m2 (nits) display brightness. It has a display area of 246 mm x 184 mm (9.7 inches x 7.2 inches), a raw resolution of 800 x 600 pixels, and has a field-replaceable backlight with a standby time of around 50,000 hours. It has a compact memory card for memory expansion up to 512MB, It also has an RS-232 serial communication port (for file transfer, printing, and logical controller communication), two USB ports (for mouse, keyboard, and printer connection), a 10/100 Base T Ethernet port in a basic configuration, and support for ControlNet communication modules. The 2711P-T12C15D2 uses DC power supply with input voltage range of 18 to 32V DC, maximum power consumption of 70W at nominal 24V DC, and maximum heat dissipation of 240 BTU/hr. It has an operating temperature range of 32 to 131 degrees Fahrenheit, a storage range of -13 to 158 degrees Fahrenheit at 5 to 95 percent non-condensing relative humidity, and is designed to withstand 15G operating shocks, as well as 2G peak vibrations at 57 to 500Hz. The 2711P-T12C15D2 uses NEMA 12, 13, and 4X interior enclosures and is cUL-us, CE, and C-TICK certified. It weighs about 3.2 kg (7.1 lb) and has a total transport size of 282 mm x 363 mm x 55 mm (11.12 inches x 14.30 inches x 2.18 inches).

The Allen-Bradley 2711P-T12C15D2 is a PanelView Plus operator terminal. The operating terminal is a dedicated part of the PanelView Plus 1250 product category, which specifically features 12.1 "color active matrix, thin film transistor (TFT) with liquid crystal display (LCD). It has a screen resolution of 800 x 600 pixels and a usable display area of 246 x 184 mm (9.7 x 7.2 inches). The available input interface of the operating terminal is a touch interface, designed to operate at a driving force of 10-110 g and the expected driving limit of 1 million compressions.

The available embedded communication interfaces of the module include one (1) RS-232 serial interface, which supports DF1 and point-to-point DH-485 communication protocols; The ControlNet communication port is used for the coaxial based Controlnet communication protocol and the RJ-45 is used for the Ethernet I/P communication protocol. This variety of communication ports enables the operating terminal to connect to traditional, mature and modern industrial networks without the need for dedicated or additional communication modules and peripherals.

☆型号：2711P-T12C15D2 标准终端 提供了有效的接口
