PXI-8252 图像采集卡设备 为相机供电

☆型号：PXI-8252 图像采集卡设备 为相机供电

【产品详情】

National Instruments PCI-8252 图像采集卡设备

National Instruments PCI-8252（部件号：779024-01）是一款符合RoHS标准的3端口图像采集卡设备。该型号是需要高数据速率的机器视觉应用的完美选择。通过此IEEE 1394a接口，用户可以同时采集图像和为相机供电。此外，借助连接到任何NI PCI-8252端口的集线器，也可以从多个相机获取数据。对于在标准配置中部署图像抓取系统（仅适用于一台相机），用户需要一根 IEEE 1394a 电缆、一台 IEEE 1394 相机和一台运行 Microsoft Windows（2000 到 XP）的个人计算机，并且至少有一个可用的 PCI 插槽。

该设备配备三个 6 针母头 1394 连接器。由于NI PCI 8252图像采集卡设备是基于PCI的设备，因此具有通用的32位PCI连接。该图像采集卡符合OHCI v1.0标准，数据传输速率高达400 Mb/s。除了三个内置的 1394 端口外，用户还可以使用标准 IEEE 1394 集线器添加更多端口。NI- IMAQ 程序 是 专门 为 IEEE 1394 设计的， 提供 了 一个 简单 易 用 的 移动 解决 方案， 可 轻松 从 符合 IEEE 1934 标准的 相机 采集 图像。NI 设备 消耗 的 功率 约为 480 mW。它配备了 3 个标准 IEEE 1394 6 针母连接器和一个 32 位通用 PCI 连接器。

该软件可以很容易地与NI测量和自动化浏览器合并。因此，用户可以轻松配置他们的相机。此外，用户还可以通过将 FireWire 摄像机连接到他们的 PC 来快速设置他们的系统;然后，他们可以立即开始获取图像。

NI 设备 的 尺寸 为 2.8 x 4.8 英寸。在物理维度上。它推荐的工作和存储温度范围分别为 0 至 60 °C 和 –20 至 60 °C，非冷凝工作和存储湿度范围分别为 20% 至 80% 和 20% 至 95%。PCI-8252 的设计符合以下电气安全标准：IEC 61010-1、EN 61010-1、UL 61010-1 和 CAN/CSA C22.2 No. 61010-1。

☆型号：PXI-8252 图像采集卡设备 为相机供电

【英文介绍】

National Instruments PCI-8252 image capture card equipment

The National Instruments PCI-8252 (Part number: 779024-01) is a RoHS compliant 3-port image capture card device. This model is perfect for machine vision applications that require high data rates. With this IEEE 1394a interface, users can simultaneously capture images and power the camera. In addition, data can also be obtained from multiple cameras with the help of a hub connected to any NI PCI-8252 port. For deploying an image capture system in a standard configuration (for one camera only), users will need an IEEE 1394a cable, an IEEE 1394 camera, and a personal computer running Microsoft Windows (2000 to XP). And at least one PCI slot is available.

The device is equipped with three 6-pin female 1394 connectors. Because the NI PCI 8252 image capture card device is a PCI-based device, it has a universal 32-bit PCI connection. The image capture card is OHCI v1.0 compliant and has data transfer rates up to 400 Mb/s. In addition to the three built-in 1394 ports, users can add more ports using the standard IEEE 1394 hub. The NI-IMAQ program is designed specifically for IEEE 1394 and provides a simple and easy-to-use mobile solution for easily capturing images from IEEE 1934 compliant cameras. NI equipment consumes about 480 mW of power. It comes with 3 standard IEEE 1394 6-pin female connectors and a 32-bit universal PCI connector.

The software can be easily merged with the NI Measurement and Automation browser. Therefore, users can easily configure their camera. In addition, users can quickly set up their system by connecting the FireWire camera to their PC; They can then immediately start acquiring images.

NI devices measure 2.8 x 4.8 inches. In the physical dimension. Its recommended operating and storage temperature ranges are 0 to 60 °C and -20 to 60 °C, respectively, and non-condensing operating and storage humidity ranges are 20 to 80% and 20 to 95%, respectively. PCI-8252 is designed to comply with the following electrical safety standards: IEC 61010-1, EN 61010-1, UL 61010-1 and CAN/CSA C22.2 No. 61010-1.

☆型号：PXI-8252 图像采集卡设备 为相机供电
