TC-205-02-4M5 smartlot线缆 实现热插拔模块间的隔离

☆型号：TC-205-02-4M5 smartlot线缆 实现热插拔模块间的隔离

【产品详情】

电缆是根据用户要求制造的，因此电缆绝缘的长度和类型

必须指定。长度必须以xmx格式指定到最接近的0.5 m，例如，a为2m0

电缆长度2.0 m。此细节必须添加到零件号的末尾。电缆的类型

绝缘是电缆部件号的一部分，用02表示低烟零卤

(LSZH)或03为UL认证电缆材料。02也是IEC 60332-3 Cat A. PVC的阻燃剂

没有覆盖电缆。订购电缆时，建议用户自备

详细信息如表1所示。

建议I/O线缆长度不超过15m。如果需要，可以指定比这个长度长的电缆

必要的，但可能会受到电压下降，失调，串扰和噪声的影响，并将呈现材料

处理问题。

内部电缆是为连接在相邻机箱中的电缆而设计的。如果

电缆需要离开外壳环境，外部电缆有更多的保护。请注意,

“外部”电缆没有铠装，不适合真正的外部使用，必须仍然是

小心对待。这些电缆在通过电缆路线时需要保护，并且应该

也不能被连接器拉动。它们应该通过运输/压缩进入橱柜

阻塞和不能被填充。

本文档中介绍的smartlot线缆可以实现热插拔模块间的隔离

根据需要选择槽位，用smartlot跳线连接。对于配套槽位电缆，允许

使用双宽机箱插座在相邻槽位上热插拔模块，请参见“可信”

双I/O配套插槽电缆，出版物ICSTT-RM315 (PD-TC700)。

☆型号：TC-205-02-4M5 smartlot线缆 实现热插拔模块间的隔离

【英文介绍】

Cables are manufactured according to user requirements, hence the length and type of cable insulation

Must be specified. The length must be specified in xmx format to the nearest 0.5 m, for example, a is 2m0

The cable length is 2.0 m. This detail must be added to the end of the part number. Type of cable

The insulation is part of the cable part number, with 02 indicating low smoke zero halogen

(LSZH) or 03 is UL certified cable material. 02 is also A flame retardant for IEC 60332-3 Cat A. PVC

There is no covering cable. When ordering cables, you are advised to bring your own cables

The details are shown in Table 1.

It is recommended that the length of an I/O cable not exceed 15m. If desired, you can specify a cable longer than this length

Necessary, but may be affected by voltage drop, offset, crosstalk and noise, and will present the material

Deal with the problem.

Internal cables are designed for cables connected in adjacent cases. if

Cables need to leave the enclosure environment, and external cables have more protection. Please note,

"External" cables are not armored, are not suitable for true external use, and must still be

Be careful. These cables need protection as they pass through the cable route, and should

It can't be pulled by the connector. They should be transported/compressed into the cabinet

Blocked and cannot be filled.

The smartlot cables described in this document can isolate hot-swapable modules

Select a slot as required and connect it with a smartlot jumper. For cables with matching slots, yes

Use a double-width chassis socket to install a hot-swappable module in an adjacent slot. For details, see Trusted.

Dual I/O matching slot cable, publication ICSTT-RM315 (PD-TC700).
