☆型号：2094-BC07-M05-M 集成轴模块 三相的转换器模块
【产品详情】
2094-BC07-M05-M 是一款 Kinetix 6000 集成轴模块。该模块是输入电压为 324-528V rms 三相的转换器模块，可接受的交流输入电压tage 范围为 360-480VAC，输入频率为 47-63 Hz。该模块的主交流输入电流为 71.0 安培标称值，浪涌值为 62.2 安培。
2094-BC07-M05-M 的公共母线跟随器的直流输入电压为 458-747V DC，输入电流为 67.7 安培，而控制电源交流输入电压为 95-264V rms，1 相，标称有效值为 110-240V。
该集成轴模块内置内部分流器和内部分流电阻器。内部分流器的连续功率为 200 瓦，峰值功率为 22.5 瓦。内部分流电阻值为 27.75 ？分流读数为 765V DC，分流导通值为 805V DC。该模块在 480VAC 时的峰值功率输出为 135 kW，效率为 97%。转换器电感和电容为 75 ？H 和 1410 ？F。该模块的短路电流额定值为 200,000 A （rms） 对称。
该模块的带宽为速度环路，频率为 500 Hz，电流环路为 1300 Hz，而模块的脉宽调制 （PWM） 频率为 4 kHz。该模块的输出额定功率为 71 瓦（20%）、101 瓦（40%）、137 瓦（60%）、179 瓦（80%）和 226 瓦（100%）。
将此模块安装到机柜时，最小底部间隙为 80 毫米（3.10 英寸），机柜深度为 302 毫米（11.9 英寸）。
☆型号：2094-BC07-M05-M 集成轴模块 三相的转换器模块
【英文介绍】
The 2094-BC07-M05-M is a Kinetix 6000 integrated axis module. The module is a three-phase converter module with input voltage of 324-528V rms. The acceptable AC input voltage tage range is 360-480VAC, and the input frequency is 47-63 Hz. The main AC input current of the module is 71.0 amp nominal value and the surge value is 62.2 amp.
The common bus follower of the 2094-BC07-M05-M has a DC input voltage of 458-747V DC with an input current of 67.7 amps, while the AC input voltage of the control supply is 95-264V rms with a 1-phase nominal RMS of 110-240V.
The integrated shaft module has a built-in internal shunt and internal shunt resistor. The internal shunt has a continuous power of 200 watts and a peak power of 22.5 watts. Is the internal shunt resistance 27.75? The shunt reading is 765V DC and the shunt on-value is 805V DC. The module has a peak power output of 135 kW at 480VAC and an efficiency of 97%. Converter inductance and capacitance of 75? H and 1410? F. The module has A short circuit current rating of 200,000 A (rms) symmetric.
The bandwidth of the module is a speed loop with a frequency of 500 Hz and a current loop of 1300 Hz, while the module's pulse width modulation (PWM) frequency is 4 kHz. The module has output power ratings of 71 watts (20%), 101 watts (40%), 137 watts (60%), 179 watts (80%) and 226 watts (100%).
When installing this module into the cabinet, the minimum bottom clearance is 80 mm (3.10 in) and the cabinet depth is 302 mm (11.9 in).
