20AC072A0AYNANC0 频率可调的变频器 提供开箱即用的性能

☆型号：20AC072A0AYNANC0 频率可调的变频器 提供开箱即用的性能

【产品详情】

20AC072A0AYNANC0 是一款频率可调的变频器。这些驱动器旨在执行并提供开箱即用的性能。Allen-Bradley 的这些 PowerFlex 70 系列变频器在节省空间、应用灵活性和可靠性方面是理想的选择。它经过预先设计，以确保卓越的可靠性。该驱动器的额定电压为 400 伏交流电，额定电流为 72 安培。该变频器的总功率输出为 50 马力。变频器具有一系列控制和性能功能。该驱动器使用具有可编程载波频率的正弦编码 PWM。输出电压范围最高可达电机额定电压。输出频率范围在 0 到 400 赫兹之间。20AC072A0AYNANC0没有人机界面模块。驱动器的正面有一个带有公司标签的空白盖。该驱动器没有编码器反馈和安全扭矩功能。该驱动器配备了用于控制驱动器的IGBT制动系统。该驱动器具有不同的可编程停止模式，包括斜坡、滑行、直流制动、斜坡保持。和 S 曲线。

20AC072A0AYNANC0 驱动器支持 2 个独立可编程的加速和减速时间。每次可编程范围为 0 至 3600 秒，增量为 1 秒。根据 IEEE C62.41-1991 标准，该驱动器支持每个峰值高达 6000 伏的线路瞬变。该驱动器具有控制逻辑噪声抗扰度，可承受峰值高达 1500 伏的喷淋电弧瞬变。20AC072A0AYNANC0 支持 3 套完整的参数数据，可针对不同的批处理过程单独加载。该驱动器采用无传感器矢量控制，可在较宽的速度范围内产生高扭矩，并可适应各个电机的特性。驱动器配有冷却风扇，用于降低内部温度。该驱动器还连接了一个由微处理器控制的散热器热敏电阻。热敏电阻可能会在温度过高时使驱动器跳闸，从而防止驱动器受到加热损坏。

☆型号：20AC072A0AYNANC0 频率可调的变频器 提供开箱即用的性能

【英文介绍】

20AC072A0AYNANC0 is an adjustable frequency converter. These drives are designed to perform and provide out-of-the-box performance. These PowerFlex 70 series drives from Allen-Bradley are ideal for space savings, application flexibility and reliability. It is pre-designed to ensure superior reliability. The driver has a rated voltage of 400 volts AC and a rated current of 72 amps. The total power output of the inverter is 50 HP. The inverter has a range of control and performance functions. The driver uses a sinusoidal coded PWM with a programmable carrier frequency. The output voltage range is up to the rated motor voltage. The output frequency ranges from 0 to 400 Hz. 20AC072A0AYNANC0 No HMI module is available. The front of the drive has a blank cover with a company label. The drive does not have encoder feedback and safe torque features. The drive is equipped with an IGBT braking system for controlling the drive. The driver has different programmable stop modes, including ramp, taxi, DC braking, ramp hold. And the S-curve.

The 20AC072A0AYNANC0 drive supports 2 independently programmable acceleration and deceleration times. Each programmable range is 0 to 3600 seconds with increments of 1 second. According to IEEE C62.41-1991 standard, the driver supports line transients up to 6000 volts per peak. The driver has control logic noise immunity and can withstand spray arc transients with peaks up to 1500 volts. 20AC072A0AYNANC0 supports three sets of complete parameter data and can be loaded independently for different batch processes. The driver uses sensorless vector control to generate high torque over a wide speed range and can be adapted to the characteristics of individual motors. The driver is equipped with a cooling fan to reduce the internal temperature. The drive is also connected to a microprocessor controlled radiator thermistor. The thermistor may cause the drive to trip when the temperature is too high, thereby preventing the drive from heating damage.
