PP886 3BSE092980R1 标准面板 具有 显示色彩和多协议连接

【产品详情】

一般信息

产品编号：编号：3BSE092980R1

ABB型号名称：PP886型

目录说明：PP886 标准面板 15”

详细描述：1280x800 宽屏 （16：10）。需要 Panel Builder 800 版本 6.2 进行配置。

为保护正面，建议使用 RX886 Touch 保护套。

取代 PP885。

触摸屏面板具有绚丽的 TFT/LED 显示色彩和多协议连接。Panel 800 的标准系列包括 PP875、PP881、PP883、PP886 和 PP895，它们是易于使用的 HMI，具有全面和集成的模板和库，适用于您需要的每个可能的过程。所有标准面板均配备高分辨率图形TFT/LED显示屏。大多数型号提供宽屏幕和高分辨率显示屏，以提高效率和出色的操作员交互。

特点和优势

易于使用

一个完全可部署的 HMI，具有全面且集成的模板和库，适用于每个可以想象的流程。Panel Builder 工具具有熟悉的 Microsoft® Windows® 环境以及多种语言支持，可实现快速、简单和高效的工程设计。

最先进的图形

TFL/LED 显示屏中基于矢量的高分辨率图形，具有基于图标的界面、导航和控制。

坚固可靠的

Panel 800 采用坚固而轻便的压铸粉末涂层铝外壳。前壳体可承受潮湿、多尘和苛刻的环境。工作温度范围为 -10°C 至 + 60°C，最大湿度为 85%。

真正的开放平台

这些面板建立在 .NET 框架附带的开放式体系结构和技术之上，能够实现多品牌控制器连接。多种连接选项可用于本地通信、扩展、远程访问等。

在使用应用程序之前先试用它

在使用之前直接从 Panel Builder 800 模拟和运行应用程序的可能性很大。

PP886 3BSE092980R1 标准面板 具有 显示色彩和多协议连接

【英文介绍】

General information

Product Number: Number: 3BSE092980R1

ABB model name: PP886

Catalog Description: PP886 Standard Panel 15"

Description: 1280x800 widescreen (16:10). Panel Builder 800 version 6.2 is required for configuration.

To protect the front, the RX886 Touch case is recommended.

Replace PP885.

The touchscreen panel features gorgeous TFT/LED display colors and multi-protocol connectivity. The Panel 800's standard family includes PP875, PP881, PP883, PP886, and PP895, which are easy to use Hmis with comprehensive and integrated templates and libraries for every possible process you need. All standard panels are equipped with high-resolution graphic TFT/LED displays. Most models offer wide screens and high-resolution displays for increased efficiency and excellent operator interaction.

Characteristics and advantages

Easy to use

A fully deployable HMI with comprehensive and integrated templates and libraries for every process imaginable. The Panel Builder tool features the familiar Microsoft® Windows® environment and multiple language support for fast, simple, and efficient engineering.

State-of-the-art graphics

Vector-based, high-resolution graphics in TFL/LED displays with icon-based interfaces, navigation and controls.

Solid and reliable

The Panel 800 features a robust and lightweight die-cast powder-coated aluminum housing. The front housing can withstand wet, dusty and harsh environments. The operating temperature ranges from -10°C to + 60°C with a maximum humidity of 85%.

A truly open platform

These panels are built on the open architecture and technology shipped with the.NET framework, enabling multi-brand controller connectivity. Multiple connection options are available for local communication, extension, remote access, and more.

Try the application before you use it

There are great possibilities to simulate and run applications directly from Panel Builder 800 before use.
