UAC389AE02 HIEE300888R0002  控制电路电源板

【产品详情】

UAC389AE02 ABB控制电路是一种用于控制其他电路或设备运行的电路。它通常由各种电子元件组成，例如晶体管、电阻、电容、二极管等，可以通过控制这些元件的状态来实现对其他电路或设备的控制。

UAC389AE02 ABB控制电路可以用于各种应用，例如电动机控制、灯光控制、温度控制、传感器控制等。它们可以实现各种功能，例如开关、调节、保护等。

外部自动停止经常用来接安全门信号，机器人在自动运行状态，当触发外部自动停止时机器人进入1类停止，手动状态下外部自动停止不生效。

初始状态下，安全板上接线端X5的4、5、6引脚短接，10、11、12引脚短接，断开11、12引脚和5、6引脚，即可触发外部自动停止。

5.外部常规停止

机器人在手动或自动运行状态，当触发外部常规停止时机器人进入1类停止。断开10、12引脚和4、6引脚，即可触发外部常规停止。

UAC389AE02 HIEE300888R0002  控制电路电源板

【英文介绍】

UAC389AE02 ABB control circuit is a circuit used to control the operation of other circuits or equipment. It is usually composed of various electronic components, such as transistors, resistors, capacitors, diodes, etc., which can be controlled by controlling the state of these components to achieve control of other circuits or devices.

UAC389AE02 ABB control circuits can be used in a variety of applications, such as motor control, light control, temperature control, sensor control, etc. They can achieve various functions, such as switching, regulation, protection, etc.

The external automatic stop is often used to receive the safety door signal. When the robot is in the automatic operation state, the robot enters the Class 1 stop when the external automatic stop is triggered, and the external automatic stop does not take effect in the manual state.

In the initial state, the 4, 5 and 6 pins of the terminal X5 on the safety board are shorted, and the 10, 11 and 12 pins are shorted, and the 11, 12 and 5 and 6 pins are disconnected to trigger the external automatic stop.

5. External routine stops

The robot is in the manual or automatic operation state, and the robot enters the type 1 stop when the external conventional stop is triggered. Disconnect pins 10 and 12 and pins 4 and 6 to trigger an external regular stop.
