3AUA0000110429L 带I/O连接器的控制单元

【产品详情】

BCU-02 3AUA0000110429 本章提供了有关安装程序和传送

检查交付情况

BCU-02 3AUA0000110429 请确保包括以下项目：

•带I/O连接器的控制单元

•存储单元

•SD/SDHC闪存卡（插入插槽）

•实时时钟电池。

确保任何物品都没有损坏的迹象。

识别不同的控制单元类型

在安装控制单元之前，请确保它具有正确的控制程序

有问题的转换器硬件。控制程序显示在

存储器单元。

还要确保控制单元对于您的设备配置是正确的。

将+24 V外部电源连接到控制单元连接器XPOW。你可以

连接第二电源以实现冗余。

将光纤电缆从转换器模块连接到控制单元。请参阅

转换器模块硬件手册中给出的说明。

 相关文件

有关一般电气安装说明，请参阅ACS880多驱动器机柜和

模块电气规划说明（3AUA0000102324[英语]），或ACS880液冷多驱动器机柜和模块电气规划（3AXD50000048634[英语]

和适用的转换器硬件手册

有关FSO xx安全功能模块的电气安装信息，请参阅

适用的FSO xx安全功能模块用户手册。

有关默认I/O连接图和有关连接的更多信息，请参阅

适用的转换器硬件手册。

3AUA0000110429L 带I/O连接器的控制单元

【英文介绍】

BCU-02 3AUA0000110429 This chapter provides information about installation procedures and transfers

Check delivery

BCU-02 3AUA0000110429 Please ensure that the following items are included:

• Control unit with I/O connector

• Storage unit

•SD/SDHC flash memory card (insert slot)

• Real-time clock battery.

Make sure nothing shows signs of damage.

Identify the different control unit types

Before installing the control unit, make sure it has the correct control program

There is a problem with converter hardware. The control program is displayed in

Memory unit.

Also make sure the control unit is configured correctly for your device.

Connect the +24 V external power supply to the control unit connector XPOW. You can

Connect a second power supply for redundancy.

Connect the fiber optic cable from the converter module to the control unit. See also

Instructions given in the converter module hardware manual.

 Related documents

For general electrical installation instructions, see ACS880 multi-drive cabinets and

Module Electrical Planning Note (3AUA0000102324[English]), or ACS880 liquid-cooled multi-drive Cabinet and Module electrical Planning (3AXD50000048634]

And applicable converter hardware manual

For electrical installation information on the FSO xx safety function module, see

Applicable FSO xx Safety function module user manual.

For the default I/O connection diagram and more information about connections, see

Applicable converter hardware manual.
