ABB UNITROL 1010 3BHE035301R1002 间接励磁系统工业机器
【产品详情】
UNITROL 1010是一款功能强大且紧凑的间接励磁系统，适用于中小型同步发电机和工业机器，已根据DNV和UL标准获得全面认证。
其先进的微处理器技术和IGBT半导体允许电流输出高达10 ADC以实现连续运行。
凭借内置双通道支持、并行运行的机器之间的高级负载共享、旋转二极管监控、自动同步和多个集成通信选项，UNITROL 1010在各种温度和振动条件下提供高性能。
UNITROL 1000系列在全球部署了20,000多个装置，适用于发电厂、船舶电力推进和辅助电源、内燃机车、港口起重机和矿用卡车
ABB UNITROL 1010 AVR提供高达10 Adc连续的最大励磁电流。标准功能包括以太网端口、USB端口、RS485、LED指示、I/O(输入和输出)、电源端子和测量端子。
认证：CE、DNL/GL、cUL、Traction
UNITROL 1010有2个不同的版本
>UNITROL 1010-0002 LIGHT–订购代码3BHE035301R0002
>UNITROL 1010-0003 BASIC–订购代码3BHE035301R0003
UNITROL 1020和UNITROL 1010是UNITROL 1000系列的最新产品。为了保证最可靠的运行，通信和控制任务被分散在单独的控制器中。AVR的非易失性闪存存储事件和数据日志，以便进行故障分析和快速故障排除。时间同步是通过以太网通信完成的，事件和数据日志是有时间戳的。
ABB UNITROL 1010 3BHE035301R1002 间接励磁系统工业机器
【英文介绍】
UNITROL 1010 is a powerful and compact indirect excitation system for small and medium-sized synchronous generators and industrial machines, fully certified according to DNV and UL standards.
Its advanced microprocessor technology and IGBT semiconductors allow current output up to 10 ADCs for continuous operation.
With built-in dual-channel support, advanced load sharing between machines running in parallel, rotating diode monitoring, automatic synchronization and multiple integrated communication options, the UNITROL 1010 delivers high performance in a wide range of temperature and vibration conditions.
With more than 20,000 units deployed worldwide, the UNITROL 1000 series is suitable for power plants, Marine electric propulsion and auxiliary power supplies, diesel locomotives, port cranes and mining trucks
The ABB UNITROL 1010 AVR offers a maximum continuous excitation current of up to 10 Adc. Standard features include Ethernet ports, USB ports, RS485, LED indicators, I/O(input and output), power terminals, and measuring terminals.
Certification: CE, DNL/GL, cUL, Traction
UNITROL 1010 comes in 2 different versions
> UNITROL 1010-0002 LIGHT - Order code 3BHE035301R0002
> UNITROL 1010-0003 BASIC - Order code 3BHE035301R0003
The UNITROL 1020 and UNITROL 1010 are the latest in the UNITROL 1000 series. In order to guarantee the most reliable operation, communication and control tasks are dispersed in separate controllers. AVR's non-volatile flash memory stores event and data logs for fault analysis and rapid troubleshooting. Time synchronization is done via Ethernet communication, and event and data logs are time-stamped.
ABB UNITROL 1010 3BHE035301R1002 间接励磁系统工业机器
【其他型号推荐】
【常见问题】
1）备件
2）保修期：12个月！
3）包装：原包装与纸箱。
4）交货时间：付款后3天内发货
5）所有货物将在发货前进行测试。
无论您对库存，价格，故障排除还是其他方面有任何疑问，我们都能满足您的需求。请致电我们，填写我们的表格，或向我们发送电子邮件-任何适合您的方式。期待您的回音！
问：您的交货时间如何？
答：我们有很多库存商品，3-5天您将收到它。
问：你们提供保修吗？
答：是的，我们为所有剩余的部件提供1年保修。
问：您可以接受哪些付款方式？
答：通常我们在中国大陆接受T/T和人民币转账
