ABB XVC767AE102 3BHB007209R0102 灵活的配置选项

【产品详情】

产品描述

ABB控制板XVC767AE102 3BHB0007209R0102设计用于控制各种工业过程。

特征

高质量的部件可实现可靠的运行

易于安装和使用

适用于恶劣工业环境的稳健设计

灵活的配置选项

主控板为驱动器的控制中枢，包括控制电源、调制脉冲的产生、控制方式及保护逻辑等四部分电路。它接受来自面板和外控接口的信号，控制和保护射频单元的工作，同时它把驱动器运行的状态信号输到面板和外控接口。

IGBT主控板主要以高频感应加热主控制板和两个驱动为主，高频板技术采用了SG3525A作为PWM脉冲形成，输出脉冲频率范围20KHZ—60KHZ,脉冲间隔互为180度，死区时间可以自行调整。可适用于IGBT全桥逆变串联谐振感应加热装置用斩波器调压调功。

ABB XVC767AE102 3BHB007209R0102 灵活的配置选项

【英文介绍】

Product description

The ABB control board XVC767AE102 3BHB0007209R0102 is designed to control various industrial processes.

trait

High quality components enable reliable operation

Easy to install and use

Robust design for harsh industrial environments

Flexible configuration options

The main control board is the control center of the driver, including control power supply, modulation pulse generation, control mode and protection logic. It accepts the signal from the panel and the external control interface, controls and protects the work of the RF unit, and it transmits the status signal of the driver operation to the panel and the external control interface.

The IGBT main control board is mainly composed of high frequency induction heating main control board and two drivers. The high frequency board technology adopts SG3525A as PWM pulse formation, the output pulse frequency range is 20Khz-60khz, the pulse interval is 180 degrees each other, and the dead time can be adjusted by itself. It can be applied to voltage and power regulation by chopper of IGBT full-bridge inverter series resonant induction heating device.
