ABB-DO810 数字输出 输出具有短路过压和过温保护

【产品详情】

基本信息

货号 3BSE008510R1

类型 数字输出

信号规格 24V 直流（12 - 32 V 直流），0.5 A

通道数 16

信号类型 电流源，限流

哈特 不

该模块有 16 个数字输出。输出电压范围为 10 至 30 伏，最大连续输出电流为 0.5 A。输出具有短路、过压和过温保护。输出分为两个独立隔离的组，每组有八个输出通道和一个电压监控输入。每个输出通道由短路和过热保护高边驱动器、EMC保护元件、感性负载抑制、输出状态指示LED和光隔离栅组成。

如果电压消失，过程电压监控输入会发出通道错误信号。错误信号可以通过模块总线读取。输出具有电流限制和过热保护。如果输出过载，输出电流将受到限制。

特点和优点

16 个通道，用于 24 V 直流电流源输出

2 组隔离，每组 8 个通道，带过程电压监控

输出状态指示灯

OSP 在检测到错误时将输出设置为预定状态

接地和 30 V 短路保护

过压和过温保护

ABB-DO810 数字输出 输出具有短路过压和过温保护

【英文介绍】

Basic information

Item number 3BSE008510R1

Type digital output

Signal specification 24V DC (12-32 V DC), 0.5A

Number of channels 16

Signal Type Current source, current limiting

Hatno

The module has 16 digital outputs. The output voltage ranges from 10 to 30 volts, with A maximum continuous output current of 0.5 A. The output is protected against short circuit, overvoltage and overtemperature. The outputs are divided into two independently isolated groups, each with eight output channels and a voltage monitoring input. Each output channel consists of short circuit and overheat protection high side drivers, EMC protection elements, inductive load suppression, output status indicator leds and optical isolation barriers.

If the voltage disappears, the process voltage monitoring input emits a channel error signal. The error signal can be read through the module bus. The output has current limitation and overheat protection. If the output is overloaded, the output current will be limited.

Features and advantages

16 channels for 24 V DC current source output

2 groups of isolation, 8 channels each, with process voltage monitoring

Output status light

The OSP sets the output to a scheduled state when an error is detected

Ground and 30 V short circuit protection

Over voltage and over temperature protection
