81EU01E-E 带发射器的输入模块 ABB

【产品详情】

应用程序

输入模块用作以下模块的替代品

带发射器的输入模块:

81 ea01-e / R1010

无校正功能

- 2线传感器，4…20ma，由模块供电

- 4线传感器，0/4…20 mA，与供应从mod规则

- 4线传感器，0/4…20ma，带外置电源

81 ea01-e / R1111

具有校正功能，无未校正输出

值(原始值)

- 2线传感器，4…20ma，由模块供电

- 4线传感器，0/4…20 mA，与供应从mod规则

- 4线传感器，0/4…20ma，带外置电源

81 ea01-e / R1112

具有校正功能，可输出未校正值

(原始值)

- 2线传感器，4…20ma，由模块供电

- 4线传感器，0/4…20 mA，与供应从mod规则

- 4线传感器，0/4…20ma，带外置电源

该模块共包含5个功能单元。每一个功能单元可用于任何类型的输入模式。任何合是可能的。分配和设置所有的参数可以很容易地编程使用配置列表。程序编制的值存储在EEPROM以确保它们在发生故障时不会丢失电源故障。它们可以随时更改。每个模拟信号最多可分配4个极限值。在一个输入模块中，多达5个独立的校正或滤波可以进行计算。编程是由构建功能块。与此相关的条件申请将被考虑在内。

特性

该模块可以插入任何PROCONTROL站带有外部电源单元。它配备了一个用于PROCONTROL站总线的标准接口。模块以形式发送转换后的输入信号

通过车站总线向PROCONTROL总线发送电报系统。电报在发出和发送之前都要经过核对用测试标志标记。这确保了接收模块规则可以检查它们的无错误传输。通过车站总线接收的电报，例如用于校正计算，由模块检查是否无错误基于测试标志的传输。所作的规定是为了消除模块的功能单元和车站总线之间的干扰。一种防短路和监控的发射机电源是否可用于各功能单元，适用于各种应用程序。

内部监控电路或输入的响应信号监测功能以干扰的形式表示，平衡公告ST(一般干扰)在前面模块面板。

81EU01E-E 带发射器的输入模块 ABB

【英文介绍】

Application program

The input module is used as a replacement for the following modules

Input module with transmitter:

81 ea01-e / R1010

No correction function

- 2-wire sensor, 4... 20ma, powered by the module

- 4-wire sensor, 0/4... 20 mA, with supply rules from mod

- 4-wire sensor, 0/4... 20ma with external power supply

81 ea01-e / R1111

With correction function, no uncorrected output

Value (original value)

- 2-wire sensor, 4... 20ma, powered by the module

- 4-wire sensor, 0/4... 20 mA, with supply rules from mod

- 4-wire sensor, 0/4... 20ma with external power supply

81 ea01-e / R1112

With correction function, can output uncorrected value

(original value)

- 2-wire sensor, 4... 20ma, powered by the module

- 4-wire sensor, 0/4... 20 mA, with supply rules from mod

- 4-wire sensor, 0/4... 20ma with external power supply

The module contains a total of 5 functional units. Each function unit can be used for any type of input mode. Any combination is possible. Assigning and setting all parameters can be easily programmed using configuration lists. The programmed values are stored in EEPROM to ensure that they do not lose power failure in the event of a failure. They can be changed at any time. Each analog signal can be assigned a maximum of 4 limits. In one input module, up to 5 independent corrections or filters can be calculated. Programming is made up of building functional blocks. Applications for conditions related to this will be taken into account.

peculiarity

The module can be plugged into any PROCONTROL station with an external power supply unit. It comes with a standard  interface for the PROCONTROL station bus. The module sends the converted input signal in form

The telegraph system is sent to the PROCONTROL bus via the station bus. Messages are checked and marked with test marks before they are sent and sent. This ensures that the receiving modules  rule can check their error-free transmissions. Telegrams received via the station bus, for example for correcting  calculations, are checked by the module for error-free transmission based on test flags. The provisions are made to eliminate interference between the module's functional  unit and the station bus. A transmitter power supply that is short circuit-proof and monitored is available for various functional units and suitable for various applications.

The internal monitoring circuit or input response signal monitoring function is represented in the form of interference , balanced bulletin ST(general interference) on the front module panel.
