YPP105F 电源模块 ABB  输入电压范围

【产品详情】

品牌:ABB

P/n:YPP105F

原产地:美国

产品参数

型号：YPP105F

输入电压：AC 100-240V

输出电压：DC 24V

输出电流：4.5A

功率：105W

工作温度：-25℃~+70℃

尺寸：120mm×60mm×35mm

产品规格

输入电压范围广，适用于不同地区的电源标准。

输出电压稳定，适用于需要稳定电源的设备。

体积小巧，易于安装。

抗干扰能力强，适用于嘈杂环境下的设备。

应用领域

工业自动化

机器人控制

通讯设备

家用电器

产品介绍

ABB YPP105F 是一款的电源模块，采用高品质的材料和先进的技术制造而成。其输入电压范围广，输出电压稳定，适用于工业自动化、机器人控制、通讯设备以及家用电器等领域。产品体积小巧，易于安装，抗干扰能力强，适用于嘈杂环境下的设备。如有进一步的问题或需求，请联系我们的客服人员。

电源模块是一种可以直接贴装在印刷电路板上的电源转换器，按变换方式一般分为AC转DC或DC转DC。随着科技的发展，电源体积趋向模块化和小型化，于是出现了电源模块。其集成度最高，将开关电源的主要电路集成在芯片中，可以实现宽频调制、隔离及多种保护等功能。

常见的基本原理由以下部分组成，输入整流滤波器，包含整流桥和输入滤波电容。单片开关电源，包括功率开关管、控制器及MOSFET。还有高频变压器、漏级钳位保护电路、光耦反馈电路、输出整流滤波器、偏置电路等部分组成。电源模块通过输入整流滤波器一般可以适配交流85~265V或直流100370V的输入电压范围，频率有47400Hz选择，常规一般为50/60Hz。因为它具有小体积、高集成度、高性价比和最佳性能指标，只需要最简的外围电路，配上少量分立式元件即可使用。并且拥有高效率、高可靠性、设计灵活等优点，现已成为开发设计中小功率开关电源的优选集成电路.

选择电源模块方案的技术要求低，设计简单，占用空间小，可靠性高，并且可随时变换方案。当产品设计需更改时，只需并联或替换电源模块即可。因此广泛应用于工控、机械设备、船舶、航空航天、通讯、军工、数据通信、手持电子产品、仪器仪表、LED照明、智能化、电力、铁路、安防、矿业、医疗、汽车电子等多个领域。

目前单个电源模块几平很难通过SURGE、EFT、CE、RE等EMC实验，尽管国外的产品寿命长、可靠性高、EMI控制很好，但是其抗干扰性的性能仍不够强。开关电源大多数是通过UL及3C认证的，EMI性能是有保证的，但是模块化后不通过是因为测试EMI的方法，想要让设备通过EMC测试还需做好外围电路设计

先择申源模块最好是选择功率在所用的30 -80%为宜，一般这个功率范用内其各项性能发挥稳定可靠。等级分类主要有商用级、工业级和军用级，不同的等级对工作温度、震动、湿度等要求不同。为了保证产品长期稳定可靠的工作，因此在选择产足时，要考虑实际应用环境。

YPP105F 电源模块 ABB  输入电压范围

【英文介绍】

Brand :ABB

P/n:YPP105F

Country of Origin: USA

Product parameter

Model: YPP105F

Input voltage: AC 100-240V

Output voltage: DC 24V

Output current: 4.5A

Power: 105W

Operating temperature: -25℃~+70℃

Size: 120mm×60mm×35mm

Product specification

Wide input voltage range, suitable for different regional power supply standards.

Stable output voltage, suitable for equipment requiring stable power supply.

Small size, easy to install.

Strong anti-interference ability, suitable for noisy environment equipment.

Application field

Industrial automation

Robot control

Communication equipment

Household appliance

Product introduction

ABB YPP105F is a power module manufactured with high quality materials and advanced technology. Its input voltage range is wide, output voltage is stable, suitable for industrial automation, robot control, communication equipment and household appliances and other fields. Small size, easy to install, strong anti-interference ability, suitable for noisy environment equipment. For further questions or requests, please contact our customer service staff.

The power module is a power converter that can be mounted directly on the printed circuit board, which is generally divided into AC to DC or DC to DC according to the conversion method. With the development of science and technology, the volume of power supplies tends to be modular and miniaturized, so there is a power module. The main circuit of the switching power supply is integrated in the chip, which can realize the functions of broadband modulation, isolation and a variety of protection.

The common basic principle consists of the following parts, the input rectifier filter, including the rectifier bridge and the input filter capacitor. Monolithic switching power supply, including power switching tube, controller and MOSFET. There are also high frequency transformer, leakage clamp protection circuit, optocoupler feedback circuit, output rectifier filter, bias circuit and other parts. The power module can generally adapt the input voltage range of AC 85~265V or DC 100370V through the input rectifier filter, and the frequency is 47400Hz, and the general frequency is 50/60Hz. Because it has a small size, high integration, high cost performance and the best performance indicators, only the simplest peripheral circuit is required, with a small number of discrete components can be used. And has the advantages of high efficiency, high reliability, flexible design, etc., has become the optimal integrated circuit for the development and design of small and medium power switching power supply.

The selection of power module scheme has low technical requirements, simple design, small space occupation, high reliability, and can be changed at any time. When the product design needs to be changed, just parallel or replace the power module. Therefore, it is widely used in industrial control, machinery and equipment, ships, aerospace, communications, military, data communication, handheld electronic products, instruments and meters, LED lighting, intelligence, electric power, railway, security, mining, medical, automotive electronics and other fields.

At present, a single power module is difficult to pass SURGE, EFT, CE, RE and other EMC experiments, although foreign products have long life, high reliability, and good EMI control, but their anti-interference performance is still not strong enough. Most of the switching power supply is through UL and 3C certification, EMI performance is guaranteed, but the modularization is not passed because of the test EMI method, want to let the equipment through the EMC test also need to do a good peripheral circuit design

The preferred source module is best to choose the power in the used 30-80% is appropriate, generally this power model within its performance is stable and reliable. There are mainly commercial grade, industrial grade and military grade, and different grades have different requirements for working temperature, vibration, humidity and so on. In order to ensure the long-term stable and reliable work of the product, it is necessary to consider the actual application environment when choosing full production.
