UFC921A102 控制器线路板 ABB

【产品详情】

货号：UFC921A102

订货号：3BHE024855R0102

该产品是ABB公司生产的控制器。以下是产品的一些规格和技术说明：

输入电压：24VDC

输出电压：24VDC

最大输出电流：10A

保护等级：IP20

工作温度范围：-20℃至+60℃

该产品可广泛应用于控制和自动化领域，如工业机器人和自动化生产线等。其他相关型号包括UFC901A101和UFC921A102等。

控制器线路板按层数来分的话分为单面板，双面板，和多层线路板三个大的分类。

首先是单面板，在最基本的PCB上，零件集中在其中一面，导线则集中在另一面上。因为导线只出现在其中一面，所以就称这种PCB叫作单面线路板。单面板通常制作简单，造价低，但是缺点是无法应用于太复杂的产品上。

双面板是单面板的延伸，当单层布线不能满足电子产品的需要时，就要使用双面板了。双面都有覆铜有走线，并且可以通过过孔来导通两层之间的线路，使之形成所需要的网络连接。

多层板是指具有三层以上的导电图形层与其间的绝缘材料以相隔层压而成，且其间导电图形按要求互连的印制板。多层线路板是电子信息技术向高速度、多功能、大容量、小体积、薄型化、轻量化方向发展的产物。

线路板按特性来分的话分为软板(FPC)，硬板(PCB)，软硬结合板(FPCB)。

UFC921A102 控制器线路板 ABB

【英文介绍】

Item number: UFC921A102

Order number: 3BHE024855R0102

This product is a controller produced by ABB Company. The following are some specifications and technical instructions of the products:

Input voltage: 24VDC

Output voltage: 24VDC

Maximum output current: 10A

Protection level: IP20

Operating temperature range: -20℃ to +60℃

The product can be widely used in control and automation fields, such as industrial robots and automated production lines. Other related models include the UFC901A101 and UFC921A102.

The circuit board is divided into three large categories according to the number of layers: single panel, double panel, and multi-layer circuit board.

The first is a single panel, in the most basic PCB, the parts are concentrated on one side, the wire is concentrated on the other side. Because the wire only appears on one side, this PCB is called a single-sided circuit board. Single panel is usually simple to make, low cost, but the disadvantage is that it can not be applied to too complex products.

Dual panel is an extension of the single panel, when the single-layer wiring can not meet the needs of electronic products, it is necessary to use dual panel. Both sides are covered with copper and have wiring, and the line between the two layers can be guided through the hole to form the required network connection.

Multilayer board refers to a printed board with more than three layers of conductive graphics layer and the insulating material between them are separated by layers, and the conductive graphics between them are interconnected according to requirements. Multilayer circuit board is the product of the development of electronic information technology to high speed, multi-function, large capacity, small volume, thin shape and light weight.

According to the characteristics of the circuit board is divided into soft board (FPC), hard board (PCB), soft and hard combined board (FPCB).
