KUC755AE105 ABB  励磁功率单元

【产品详情】

KUC755AE105 ABB 励磁功率单元向同步发电机转子提供励磁电流；而励磁调节器则根据输入信号和给定的调节准则控制励磁功率单元的输出。励磁系统的自动励磁调节器对提高电力系统并联机组的稳定性具有相当大的作用。尤其是现代电力系统的发展导致机组稳定极限降低的趋势，也促使励磁技术不断发展。同步发电机的励磁系统主要由功率单元和调节器（装置）两大部分组成。如图发电机励磁系统所示：

发电机励磁系统

发电机励磁系统

其中励磁功率单元是指向同步发电机转子绕组提供直流励磁电流的励磁电源部分，而励磁调节器则是根据控制要求的输入信号和给定的调节准则控制励磁功率单元输出的装置。由励磁调节器、励磁功率单元和发电机本身一起组成的整个系统称为励磁系统控制系统。励磁系统是发电机的重要组成部份，它对电力系统及发电机本身的安全稳定运行有很大的影响。

同步发电机的励磁控制系统一般由励磁功率单元和励磁调节器两部分组成，励磁功率单元向同步发电机转子提供直流电流，即励磁电流;励磁调节器根据输入信号和给定的调节准则控制励磁功率单元的输出。整个励磁自动控制系统由励磁调节器、励磁功率单元和发电机构成的一个反馈控制系统。

KUC755AE105 ABB  励磁功率单元

【英文介绍】

The KUC755AE105 ABB excitation power unit provides excitation current to the synchronous generator rotor; The excitation regulator controls the output of the excitation power unit according to the input signal and the given regulation criteria. The automatic excitation regulator of excitation system plays an important role in improving the stability of parallel units of power system. In particular, the development of modern power systems leads to the trend of reducing the stability limit of units, and also promotes the continuous development of excitation technology. The excitation system of synchronous generator mainly consists of two parts: power unit and regulator (device). The generator excitation system is shown as follows:

Generator excitation system

Generator excitation system

The excitation power unit is a part of the excitation power supply that provides DC excitation current to the rotor winding of the synchronous generator, and the excitation regulator is a device that controls the output of the excitation power unit according to the input signal required by the control and the given regulation criteria. The whole system composed of excitation regulator, excitation power unit and generator itself is called excitation system control system. Excitation system is an important part of generator, it has a great impact on the safe and stable operation of power system and generator itself.

The excitation control system of synchronous generator generally consists of two parts: excitation power unit and excitation regulator. The excitation power unit provides DC current to the rotor of synchronous generator, namely excitation current. The excitation regulator controls the output of the excitation power unit according to the input signal and the given regulation criteria. The whole excitation automatic control system is a feedback control system composed of excitation regulator, excitation power unit and generator.
