61C22是信实电气制造的本地I/O头。它也可能是由Asea Brown Boveri和Baldor Reliance出售的。

61C22 是专为 AutoMax DCS 上的轨道 I/O 系统创建的轨道安装式数字本地磁头。当在轨道式 I/O 系统中使用时，允许定制以满足系统要求。四个不同的数字 I/O 能够与设备上的单个 I/O 端口通信。然后，可以连接到远程I/O头的数字I/O数量可以从64个增加到256个。该模块还预装了自己的电源，能够为四个数字I/O模块的总电源轨供电。

61C22的面板上有很多组件。它有一个 250VAC MDQ 4 安培可更换保险丝室。它有一组 LED 指示灯，标记为电源、COM、轨道故障 0、轨道故障 1、轨道故障 2 和轨道故障 3。有五个 12 点公头端口标记为 RAIL 0、RAIL 1、RAIL 2、RAIL 3 和 INPUT。其中四个端口是 I/O 通信端口，最后一个是远程磁头通信端口。

61C22 的背面有一个安装支架，可用于将模块放在机架组件上。该模块的顶部和侧面都有工厂钻孔。这些孔对模块至关重要，因为它们允许空气流入模块的内部电路。

关于 61C22 的常见问题

61C22使用什么系统？

61C22 使用 AutoMate 20/20E I/O 系统。61C22 围绕定制 LSI 芯片构建，以确保可靠性和提高速度。

61C22有什么作用？

61C22 是一款通信多路复用器，允许四个输入/输出与 20C20 的 AutoMate 61/22E 处理器单元上的 I/O 通信端口通信。

当 Reliance 61C22 上的“COM”LED 亮起时，这意味着什么？

当“COM”指示灯亮起时，处理器和61C22上的本地磁头之间正在进行通信。
