CPU 板包含微处理器和 RAM 存储器、实时时钟、LED 指示灯、INIT 按钮和 CompactFlash 接口。特点和好处

可靠性和简单的故障诊断程序

模块化，允许逐步扩展

IP20 等级保护，无需外壳

控制器可配置 800xA 控制生成器

控制器具有 EMC 认证

使用一对 BC810 的分段 CEX-Bus

基于通信连接标准的硬件（以太网、PROFIBUS DP 等）

内置冗余以太网通讯端口

CPU 板包含微处理器和 RAM 存储器、实时时钟、LED 指示灯、INIT 按钮和 CompactFlash 接口。

PM864A 控制器的底板上有两个 RJ45 以太网端口（CN1、CN2）用于连接控制网络，以及两个 RJ45 串行端口（COM3、COM4）。其中一个串行端口（COM3）是带有调制解调器控制信号的 RS-232C 端口，而另一个端口（COM4）是隔离的，用于连接配置工具。控制器支持 CPU 冗余以提高可用性（CPU、CEX-Bus、通信接口和 S800 I/O）。

ABB PM864AK01 3BSE018161R1 数据采集模块

The CPU board includes microprocessor and RAM memory, real-time clock, LED indicator, INIT button and CompactFlash interface. Features and benefits

Reliability and simple fault diagnosis procedures

Modular, allowing gradual expansion

IP20 grade protection, no need for shell.

The controller can be configured with 800xA control generator.

The controller has EMC certification.

Segmented CEX-Bus using a pair of BC810.

Hardware based on communication connection standard (Ethernet, PROFIBUS DP, etc.)

Built-in redundant Ethernet communication port

The CPU board includes microprocessor and RAM memory, real-time clock, LED indicator, INIT button and CompactFlash interface.

There are two RJ45 Ethernet ports (CN1, CN2) connected to the control network and two RJ45 serial ports (COM3, COM4) on the backplane of the PM864A controller. One of the serial ports (COM3) is an RS-232C port with modem control signal, while the other port (COM4) is isolated and used to connect configuration tools. The controller supports CPU redundancy to improve availability (CPU, CEX-Bus, communication interface and S800 I/O).
