AC800M及相关模件均采用DIN导轨式安装，每个模件由一可拆卸单元及相互连接的基座组成，基座实现模件间的外部连接，包括供电及通讯。

控制器的核心为处理器模件及基座，其上安装的两个IEEE802.3以太网口可连接至控制网、监控系统或Control Builder M组态工具。

同时还提供了两个可替代以太网方式的RS232 C口可连接至Control Builder或监控系统或其它符合通讯协议要求的子系统。用户也可自定义通讯协议。其中一个RS232 C口用于短信息的传递，如：编程工具，因此其只提供部分RS232 C 信息。另一通讯口用于长信息的传输，它提供了完全格式的RS232 C 信息，如：调制解调器的控制。

模件的左侧有一用于通讯扩展（CEX）的插槽。系统提供了Profibus DP、FF、Modbus等多种类型的通讯模件，控制器可连接多至12个通讯模件。

特性

PM861 RISC 32位实时多任务微处理器

16 MB RAM 具有错误检测与校正

后备电池保持,包括电池电压监控

EPROM, 串行, 16 Kbit

内置温度检测设备

Watchdog

支持12 个现场总线模件扩展

2 个 Ethernet 接口, 2个RS 232C接口，ModuleBus 电气及光纤扩展

现场控制器可冗余设置，切换时间小于10ms

多至16个任务，小任务周期1ms，SOE顺序发生事件分辨率小于1ms

大量的I/O模件扩展
