CI773F 3BDH000395R0001 PROFIBUS-DP主站通信模块 实现高达 12 Mbps 的数据传输速度

☆型号：CI773F 3BDH000395R0001   PROFIBUS-DP主站通信模块    实现高达 12 Mbps 的数据传输速度

【产品详情】

产品编号:3BDH000395R0001

ABB型号:CI773F

目录描述:CI773F PROFIBUS DP主模块

产品净深度/长度:75mm

产品净高:135mm

产品净宽:28mm

产品净重:0.1 kg

详细描述:CI773F PROFIBUS DP主控模块

CI773F 3BDH000395R0001是ABB制造的PROFIBUS-DP主站通信模块，用于其控制系统。它利用PROFIBUS-DP协议在工业自动化网络中充当控制器和现场设备之间的桥梁。以下是其功能和主要特性的细分：

功能：

CI773F 在控制系统（例如 AC 700F 或 AC 900F 控制器）和连接到网络的 PROFIBUS-DP 现场设备之间建立通信。它将来自控制器的数据信号转换为设备（传感器、执行器）可以理解的格式，反之亦然。这使得控制系统能够监视和控制自动化过程中的各种设备。

主要特点：

PROFIBUS-DP主站：作为PROFIBUS-DP主站设备运行，启动通信并管理与网络上的从站设备（现场设备）的数据交换。

支持 AC 700F 和 AC 900F 控制器：设计用于 ABB 的 AC 700F 和 AC 900F 控制器系列，通常用于工业自动化应用。

DP-V0/V1：支持两种 PROFIBUS-DP 版本（V0 和 V1），为现有或升级的网络提供灵活性。

12 Mbit/s 数据速率：在 PROFIBUS-DP 网络上实现高达 12 Mbps 的数据传输速度。

1 x D-Sub 端子 （9 极）：提供 D-sub 9 针连接器，用于物理连接到 PROFIBUS-DP 网线。

冗余支持：可能支持冗余网络配置（需要额外的硬件），以增强关键应用程序中的系统可用性。（请仔细检查数据表进行确认）。

DIN导轨安装：设计用于轻松安装在控制柜的标准DIN安装导轨上。

应用：

CI773F 3BDH000395R0001用于各种工业自动化应用，其中PROFIBUS-DP是首选的通信协议，ABB的AC 700F或AC 900F控制器管理自动化过程。以下是一些示例：

工厂自动化：将生产线或机器上的传感器和执行器连接到 AC 700F/900F 控制器，用于监测和控制目的（例如，电机控制、过程变量监控）。

过程控制系统：将压力变送器、流量计和控制阀等现场设备集成到 PROFIBUS-DP 网络中，用于化工、石油和天然气以及发电等行业的过程自动化。

楼宇自动化系统：使用PROFIBUS-DP将大型建筑物中的环境传感器和执行器（例如温度、照明）连接到中央控制系统。

【英文介绍】

Product ID:3BDH000395R0001

ABB Type Designation:CI773F

Catalog Description:CI773F PROFIBUS DP Master Module

Product Net Depth / Length:75 mm

Product Net Height:135 mm

Product Net Width:28 mm

Product Net Weight:0.1 kg

Long Description:CI773F PROFIBUS DP Master Module

CI773F 3BDH000395R0001 is a PROFIBUS-DP master station communication module manufactured by ABB for its control system. It utilizes the PROFIBUS-DP protocol to act as a bridge between controllers and field devices in industrial automation networks. Here is a breakdown of its functions and key features:

Features:

The CI773F establishes communication between a control system, such as an AC 700F or AC 900F controller, and a PROFIBUS-DP field device connected to the network. It converts the data signal from the controller into a format that the device (sensor, actuator) can understand and vice versa. This enables the control system to monitor and control various devices in the automation process.

Main features:

PROFIBUS-DP master station: Operates as a PROFIBUS-DP master station device, initiating communication and managing data exchange with the slave station devices (field devices) on the network.

Support for AC 700F and AC 900F controllers: Designed for ABB's family of AC 700F and AC 900F controllers, commonly used in industrial automation applications.

DP-V0/V1: Supports two PROFIBUS-DP versions (V0 and V1) to provide flexibility for existing or upgraded networks.

12 Mbit/s Data rate: Data transfer speeds of up to 12 Mbps are achieved on PROFIBUS-DP networks.

1 x D-Sub terminals (9 poles) : D-sub 9-pin connectors are provided for physical connection to PROFIBUS-DP network cables.

Redundancy support: Redundant network configurations (requiring additional hardware) may be supported to enhance system availability in critical applications. (Please check the data sheet carefully for confirmation).

DIN Rail mounting: Designed for easy mounting on standard DIN mounting rails in control cabinets.

Applications:

CI773F 3BDH000395R0001 is used in various industrial automation applications where PROFIBUS-DP is the preferred communication protocol and ABB's AC 700F or AC 900F controllers manage automated processes. Here are some examples:

Factory automation: Connecting sensors and actuators on production lines or machines to AC 700F/900F controllers for monitoring and control purposes (e.g., motor control, process variable monitoring).

Process control systems: Integrate field equipment such as pressure transmitters, flow meters and control valves into the PROFIBUS-DP network for process automation in industries such as chemical, oil and gas, and power generation.

Building automation systems: Use PROFIBUS-DP to connect environmental sensors and actuators (e.g. temperature, lighting) in large buildings to a central control system.
